NETGEAR AV Line M4350-24M4X4V 24-Port 2.5G / 4-Port 10G PoE++ Compliant Managed Switch

NETGEAR AV Line M4350-24M4X4V 24-Port 2.5G / 4-Port 10G PoE++ Compliant Managed Switch is built for AV and broadcast network environments where powered copper endpoints, faster copper links, and higher-speed uplinks all need to live in the same chassis. Based on the source details, this switch provides 33 total connections supporting up to 25 GbE, making it a strong fit for mixed-role media and infrastructure networks.

Highlights

• 24 x RJ45 2.5 GbE PoE++ ports for high-density powered endpoint connectivity
• 4 x RJ45 10 GbE PoE++ ports for higher-speed copper connections
• 4 x 25 GbE uplink ports for upstream bandwidth and aggregation
• 522 W PoE budget for powered AV device support
• Layer 3 services, IGMP Snooping, and jumbo frames up to 12,000 bytes

Quick Specs & Uses

• Networking I/O: 33 total connections supporting up to 25 GbE
• Ports: 24 x RJ45 2.5 GbE PoE++, 4 x RJ45 10 GbE PoE++, 4 x 25 GbE, 1 x RJ45 Gigabit Ethernet
• Other I/O: 1 x USB-C, 2 x USB-A
• Stackable: Yes
• Layer services supported: Layer 3
• Supported protocols: Auto-MDI/MDI-X, DHCP Server, IGMP Snooping, RIPv6
• Jumbo frame support: 12,000 bytes
• MAC address table size: 16K
• Security features: DHCP Snooping
• Forwarding rate: 297.6 Mpps
• Switching bandwidth: 400 Gb/s
• Packet buffer: 32 Mb
• CPU: Quad-core up to 1.8 GHz Cortex A57
• Memory: 4 GB DDR4
• PoE power budget: 522 W
• Power supply type: Internal
• Cooling system: Fan, 34.8 dB noise level
• Rack mountable: Yes, 1RU
• Dimensions: 17.3 x 15.7 x 1.7 in / 440 x 400 x 43.2 mm
• Weight: 16.2 lb / 7.38 kg

Why It Helps

In real AV systems, the switch often has to do more than one job. It needs to support powered endpoints, handle mixed-speed copper connections, and still leave enough uplink bandwidth so the network can scale cleanly. The M4350-24M4X4V fits that role well, combining practical access-layer connectivity with faster uplinks and AV-aware management features in a single 1RU platform.

System Characteristics

• Mixed-speed copper design supports both standard AV endpoints and higher-speed device connections
• 25 GbE uplinks add headroom for aggregation and backbone traffic
• 522 W PoE budget makes the switch practical for powered endpoint deployments
• Layer 3, IGMP Snooping, and jumbo frame support align it with multicast-heavy AV workflows
• Stackable 1RU format helps it fit cleanly into scalable rack builds

What’s In The Box

Please refer to the Specifications tab for the exact included items.
