NETGEAR ProSafe GS728TPP 24-Port Gigabit PoE+ Compliant Managed Network Switch

NETGEAR ProSafe GS728TPP 24-Port Gigabit PoE+ Compliant Managed Network Switch is built for networks that need serious PoE power in a rackmount managed switch. Based on the image source, it provides Gigabit Ethernet PoE+ ports rated at 30W with 802.3at support, a large 380W PoE power budget, and Layer 2, Layer 3, and Layer 4 service support.

Highlights

• Gigabit PoE+ connectivity with 30W 802.3at support
• 380W total PoE budget for powered endpoint deployments
• Layer 2, Layer 3, and Layer 4 support for managed networks
• 56 Gb/s switching bandwidth with 41.67 Mpps forwarding rate
• 1U rackmount design with internal power supply

Quick Specs & Uses

• Networking I/O: RJ45 Gigabit Ethernet PoE+ ports, 30W, 802.3at
• Other I/O: 1x USB-A
• Stackable: No
• Layer services: Layer 2, Layer 3, Layer 4
• Supported protocols: Auto-VoIP, DHCP Server, DoS, IGMP Snooping, IPv4, IPv6, Link Aggregation, RADIUS, TLS
• Queuing: Weighted Round Robin (WRR)
• Jumbo frames: 10,000 bytes
• MAC address table: 16K
• Security features: DHCP Snooping, Storm Control
• Forwarding rate: 41.67 Mpps
• Switching bandwidth: 56 Gb/s
• Packet buffer: 1.5 MB
• PoE power budget: 380 W
• Power draw: 427 W max, 26 W active, 14 W idle
• Input power: 100 to 240 VAC, 50 / 60 Hz
• Power supply type: Internal
• Cooling system: Fan, 33.3 dB noise level
• MTBF: 1.2 million hours
• Rack mountable: Yes, 1U
• Dimensions: 17.3 x 10.1 x 1.7 in / 440 x 257 x 43.2 mm
• Weight: 9.06 lb / 4.11 kg

Why It Helps

In a larger PoE network, port count alone is not enough. The switch also needs enough power budget, traffic control, and management features to keep the system stable. The GS728TPP gives you a 380W PoE budget, Gigabit switching, Layer 2/3/4 services, and rackmount installation in one managed platform.

System Characteristics

• 380W PoE budget gives the switch useful power headroom for larger endpoint groups
• Managed protocol support helps with voice, multicast, authentication, and network organization
• WRR queuing and jumbo frame support help support more structured traffic handling
• 1U rackmount form factor fits standard equipment racks
• Internal power supply and fan cooling make it better suited for installed environments

What’s In The Box

Please refer to the Specifications tab for the exact included items.
