Decimator MD-HX SDI/HDMI Scaling & Frame Rate Cross Converter

Decimator MD-HX SDI/HDMI Cross Converter with Scaling and Frame Rate Conversion

The Decimator MD-HX has always been a reliable tool for SDI and HDMI workflows. With Firmware v2.0, it expands into a complete signal utility platform capable of converting, generating, monitoring, and diagnosing all within a single unit.

Note: Firmware v2.0 features are available only on newer units with serial numbers starting with CLD, CLE, or CLF.

Highlights

• All-In-One Signal Tool for Conversion, Monitoring, and Diagnostics
• Supports 204 VESA HDMI Formats plus 2K Video Compatibility
• Built-In Video Test Pattern and Audio Tone Generators
• Advanced Overlays with Audio Meters, UMD, and Format Display
• Compact Design with Dual SDI Outputs and HDMI Output

Firmware v2.0 Enhancements

Expanded Format Support
Adds VESA HDMI input support and 2K formats, making it easier to integrate computers and non-broadcast sources.

Integrated Test Tools
Includes built-in video test pattern and audio tone generators for system setup and troubleshooting.

On-Screen Overlays
Displays up to 16 audio meters, graticules, UMD labels, and input/output format status directly on screen.

Core Features

The MD-HX supports HDMI and SDI cross conversion, scaling, and frame rate conversion. It allows conversion between 3G Level A and Level B and includes horizontal and vertical image flipping.

Built with a durable aluminum housing, the unit features a locking DC power connector, USB control for firmware updates, and two active SDI loop outputs for flexible signal distribution.

The front LCD and button interface provide quick control without the need for external software or dip switches.

System Characteristics

This unit is designed for real-world production use. It fits easily into flypacks, racks, or field kits and provides dependable signal management across a wide range of workflows.
