Teradek Ranger MK II 750 12G-SDI/HDMI Wireless Transmitter/Receiver Set (V-Mount)

Teradek Ranger MK II 750 12G-SDI/HDMI Wireless Transmitter/Receiver Set (V-Mount) is a professional wireless video system for broadcast, live events, handheld cameras, drones, and production monitoring. From the supplied source, it carries uncompressed video up to 750 ft / 228.6 m under line-of-sight conditions with latency listed at less than 1 ms.

The transmitter accepts HDMI 2.0 or 12G-SDI video and includes a 12G-SDI loop output for a local monitor or recorder. The receiver provides HDMI 2.0 and 12G-SDI outputs at the monitoring position, while fixed V-Mount plates keep both units ready for established broadcast battery workflows.

Highlights

• 12G-SDI/HDMI wireless transmitter and receiver set for professional 4K monitoring
• Up to 750 ft / 228.6 m line-of-sight range
• Uncompressed video transmission with less than 1 ms latency
• Supports UHD 4K60, 10-bit 4:2:2 HDR, timecode, and embedded audio
• 256-bit AES encryption, V-Mount battery plates, and support for up to six receivers

Quick Specs & Uses

• Product type: Wireless video transmitter and receiver set
• Primary workflows: Broadcast, live events, handheld production, drone work, video village, focus monitoring, and remote camera feeds
• Maximum wireless range: 750 ft / 228.6 m, line of sight
• Wireless video transmission: Uncompressed
• Latency: Less than 1 ms
• Maximum HDMI format: UHD 4K60
• HDMI color support: 8/10-bit 4:4:4 and 4:2:2 RGB/YCC
• SDI color support: 10-bit 4:2:2 YCC
• HDR support: 4K60 10-bit 4:2:2 HDR
• Timecode support: Yes
• Audio format: 2-channel, 24-bit, 48 kHz
• Embedded HDMI audio: 2-channel
• Embedded SDI audio: 2-channel
• Dedicated analog audio I/O: No
• Encryption: 256-bit AES
• Frequency ranges: 4.9 GHz, 5 GHz, and 6.4 GHz ranges
• Channel bandwidth: 40 MHz and 20 MHz
• Transmitter RF power: 23 dBm
• Receiver RF power: 21 dBm
• Bluetooth: Bluetooth 5.0 LE
• Mobile app compatibility: Android and iOS
• App functions: Settings adjustment, remote control, setup, and live-feed viewing
• Wi-Fi: No
• Cellular support: No
• Receiver support: Transmission to up to six receivers
• Battery mounting: Fixed V-Mount plates

Why It Helps

The Ranger MK II 750 is suited to production spaces where the camera needs freedom to move, but the director, focus puller, or engineering team still needs a dependable live picture. A 750 ft line-of-sight range is practical for studio floors, stages, smaller venues, handheld coverage, gimbals, and camera positions that would be awkward to reach with a long SDI cable.

The transmitter can take either HDMI 2.0 or 12G-SDI, which makes it easy to place into both cinema and broadcast camera builds. Its 12G-SDI loop output keeps a camera-side monitor or recorder active while the same signal is sent wirelessly.

At the receiver, HDMI 2.0 and 12G-SDI outputs give the production team straightforward connections for a focus monitor, director’s display, recorder, switcher, or router. With latency listed below 1 ms, the picture remains suitable for live operation where timing matters.

One transmitter can feed as many as six receivers, so the same camera signal can be distributed to several monitoring positions without installing another transmitter at the source. AES-256 encryption also helps protect the wireless feed while it moves across the production environment.

System Characteristics

• 750 ft line-of-sight operation for studios, stages, venues, and mobile camera positions
• Uncompressed wireless transport without an added transmission codec
• Sub-millisecond latency for focus, framing, and live monitoring
• 12G-SDI and HDMI 2.0 connectivity for professional UHD sources
• Support for up to six receivers from one transmitter
• 256-bit AES encryption for protected video transmission
• Bluetooth mobile control for setup and remote adjustment
• Fixed V-Mount plates for standard broadcast battery systems
• Aluminum and polycarbonate construction for production use

What’s In The Box

• 1 x Teradek Ranger MK II 750 12G-SDI/HDMI Wireless Transmitter (V-Mount)
• 2 x N-Type Antennas
• 1 x V-Mount Battery Plate for Transmitter
• 1 x Limited One-Year Manufacturer Warranty
• 1 x Teradek Ranger MK II 750 12G-SDI/HDMI Wireless Receiver (V-Mount)
• 5 x 2 dBi Antennas
• 1 x V-Mount Battery Plate for Receiver
