Teradek Ace 750 HDMI Wireless Video Transmitter and Receiver Set

Teradek Ace 750 HDMI Wireless Video Transmitter and Receiver Set is a compact wireless monitoring system for cinema, live production, corporate video, and location work. Based on the supplied source, it sends visually lossless, uncompressed HDMI video from the camera to the included receiver at distances of up to 750 ft under line-of-sight conditions.

The system supports video up to 4K30 HDR and operates with less than 1 ms of latency. This keeps the picture responsive for camera operation, directing, focus checks, client monitoring, and other production tasks where a noticeable delay would get in the way.

Highlights

• Complete HDMI wireless video set with transmitter and receiver
• Up to 750 ft line-of-sight range for studio and location monitoring
• Supports visually lossless 4K30 HDR video
• Less than 1 ms latency for responsive production viewing
• Compatible with selected Bolt 4K and Bolt 6 units

Quick Specs & Uses

• Product type: HDMI wireless video transmitter and receiver set
• Primary workflows: Camera monitoring, video village, director viewing, client monitoring, gimbal operation, corporate production, and field shooting
• Video connection: HDMI input and output
• Maximum video format: Up to 4K30 HDR
• Wireless video: Visually lossless and uncompressed
• Maximum wireless range: Up to 750 ft, line of sight
• Latency: Less than 1 ms
• Maximum receiving devices: Up to six compatible receivers or devices
• Embedded audio: HDMI 2-channel
• Timecode support: Yes
• Encryption: 256-bit AES
• Wireless bands: 5 GHz and 6 GHz
• Compatibility: Selected Bolt 4K and Bolt 6 units
• Input voltage: 7 to 18 VDC
• Operating temperature: 32 to 104°F / 0 to 40°C

Transmitter

• Function: Sends HDMI video from the camera to compatible receivers
• Maximum video format: Up to 4K30 HDR
• Embedded audio: HDMI 2-channel
• Timecode support: Yes
• Encryption: 256-bit AES
• Input power: 7 to 18 VDC

Receiver

• Function: Receives the wireless feed and outputs it over HDMI
• Maximum video format: Up to 4K30 HDR
• Embedded audio: HDMI 2-channel
• Timecode support: Yes
• Encryption: 256-bit AES
• Input power: 7 to 18 VDC

Why It Helps

This Ace 750 set gives the camera team a straightforward way to move a high-quality HDMI feed without running a long cable across the production area. The camera can stay mobile while the receiver remains with the monitor, recorder, or viewing station.

The listed 750 ft line-of-sight range makes the system a practical choice for stages, interview sets, event spaces, corporate shoots, and exterior locations. It provides useful working distance without moving into the size and complexity of a larger long-range broadcast system.

Less than 1 ms of latency keeps the image close to real time. That matters when the operator, director, or client needs to react to framing, movement, or action as it happens rather than watching a delayed preview.

The transmitter can send video to as many as six compatible receivers or devices. This allows several monitoring positions to share the same camera feed without requiring a separate wired connection for every viewer.

Wireless Monitoring

• 750 ft line-of-sight operation for studio and field production
• 5 and 6 GHz wireless support for compatible frequency operation
• Visually lossless, uncompressed transmission
• Sub-1 ms latency for live monitoring
• One-to-six transmission support for multi-viewer setups

Video, Audio & Security

• Maximum video format: 4K30 HDR
• Signal interface: HDMI
• Embedded audio: 2-channel over HDMI
• Timecode support: Yes
• Encryption: 256-bit AES

System Compatibility

• Teradek Ace 750 transmitter and receiver hardware
• Selected Teradek Bolt 4K units
• Selected Teradek Bolt 6 units

System Characteristics

• Compact transmitter and receiver design for portable production setups
• 4K30 HDR support for high-resolution monitoring
• Less than 1 ms latency for responsive camera workflows
• 5 and 6 GHz wireless operation
• AES-256 encryption for protected video delivery
• Timecode support for compatible production workflows
• Up to six receiving devices for shared monitoring

What’s In The Box

• 1 x Teradek Ace 750 Wireless Video Transmitter
• 1 x Shoe Adapter
• 1 x Ultrathin HDMI Cable, 18 in
• 1 x D-Tap to Barrel Cable, 18 in
• 1 x Limited One-Year Manufacturer Warranty for Transmitter
• 1 x Teradek Ace 750 HDMI Wireless Video Receiver
• 1 x Ultrathin HDMI Cable, 18 in
• 1 x Power Adapter, 18W 12 VDC, 6 ft
• 1 x D-Tap to Barrel Cable, 18 in
• 1 x Limited One-Year Manufacturer Warranty for Receiver
