Product Highlights
- UHD 4K NDI IP Workflow
- 44 Simultaneous NDI Video Inputs
- Up to 56 NDI Outputs for HD Workflows
- Integrated Audio Mixer with Balanced Stereo I/O
- 4TB Internal SSD
- LivePanel Pro Browser Control
Vizrt TriCaster Vizion 2RU 4K NDI UHD Live Production Switcher
- SKU:
- TCVIZION2RU0IO
- MPN:
- BDL-000000146
Free Expedited Shipping
Secure payment
Manufacturer Warranty
Authorized Dealer
Product Inquiry Form
Description
Product Overview
Vizrt TriCaster Vizion 0 SDI I/O is a 2RU IP-first live production switcher for facilities built around NDI video workflows rather than local SDI connectivity. It supports 44 simultaneous external video inputs, UHD sessions up to 2160p59.94, and extensive NDI routing for broadcast control rooms, sports production, live events, corporate communications, education AV, and remote production. Switching, audio, graphics, recording, PTZ control, and contribution tools are integrated into one scalable production platform.
LivePanel Pro Browser Control for NDI Production
LivePanel Pro gives operators browser-based access to modern widgets, low-latency video previews, intelligent state awareness, and real-time system feedback. Exclusive to TriCaster Prizm and Vizion, it supports distributed production teams that need visual confirmation and control without placing every operator at the primary system interface.
AI Keying and AR Graphics for IP Broadcast Production
TriCaster Vizion AI/R adds real-time AI-powered keying and augmented reality graphics through an optional subscription. It is designed for newsroom, sports, education, corporate broadcast, and virtual studio teams that want immersive graphics integrated into the Vizion production environment.
0 SDI I/O for Network-First NDI Production
This configuration removes physical SDI video I/O while retaining the Vizion production engine for IP-based workflows. With 44 simultaneous NDI inputs and high-capacity network connectivity, it fits facilities where cameras, converters, graphics systems, replay sources, and program feeds already move across the production network.
Live Call Connect for Zoom and Microsoft Teams Guests
Live Call Connect supports multiple simultaneous video-call inputs from Microsoft Teams, Zoom Meetings, and a web browser. Producers can bring remote contributors into broadcast, corporate communications, education AV, and hybrid-event workflows while keeping the production centered on the TriCaster environment.
NDI Broadcast Studios
A 44-input NDI architecture supports network-native control rooms that no longer require local baseband video I/O.
Sports Broadcasting
Eight M/Es, keying, graphics, PTZ control, UHD production, and IP routing support multi-camera venue and studio shows.
Live Events
NDI connectivity and remote contribution fit conferences, staged events, distributed venues, and networked production spaces.
Corporate Communications
Browser control, graphics, recording, conferencing, and NDI networking support executive broadcasts and hybrid meetings.
Education AV
PTZ integration, macros, recording, reusable graphics, and network video support campus media and lecture production.
Virtual Studio Teams
LiveSet, DataLink, Viz Flowics, keying, and optional AI/R tools support data-driven virtual production environments.
Vizrt Standard Support
TriCaster Vizion includes one year of standard support according to Vizrt's September 2026 specification. Optional advanced hardware replacement is available, and support coverage can be upgraded.
| Specification | Detail |
|---|---|
| Manufacturer SKU | BDL-000000146 |
| Video Input | 44 simultaneous external video inputs supporting compatible sources up to UHD at frame rates through 2160p59.94 |
| Network Video Input | 44 IP inputs via NDI with support for key and fill |
| Physical SDI I/O | None on the 0 SDI I/O hardware configuration |
| Network Video Output | Up to 56 IP outputs via NDI in HD sessions |
| Video Mix Outputs | Up to 8 independent HD or 2 UHD video mix outputs delivered through the IP production workflow |
| Audio Mixer | 44-channel integrated audio mixer with 8-channel audio support, DSP processing, and 4x8x8 audio input routing |
| Local Audio Input | 1 balanced stereo pair via 1/4-inch connection and 1 microphone input via 1/4-inch connection |
| Local Audio Output | 1 balanced stereo pair via 1/4-inch connection and 1 headphone output via 1/4-inch connection |
| Network Audio | NDI audio input/output; Dante and AES67 support require compatible third-party virtual sound card licenses |
| Media Players | 5 media players: 4 DDR and 1 Sound; 15 media buffers |
| Keying | LiveMatte chroma/luma keying with 44 input keyers, 4 media player keyers, 8 M/E keyers, 1 PREVIZ keyer, and 15 buffer keyers |
| Composition | 16 configurable COMP presets per bus with integrated composition and DVE-style motion sequencing |
| Virtual Sets | LiveSet technology with 30+ live virtual sets and box effects |
| DataLink | Real-time automated data input from webpages, spreadsheets, scoreboards, databases, RSS, XML, CSV, ASCII, and other supported sources |
| Recording | No software limit stated by Vizrt |
| Internal Storage | 4 TB SSD |
| PTZ Control | Up to 44 simultaneous PTZ cameras via RS232, RS422, and IP |
| Conference Calling | Multiple simultaneous video-call inputs via Microsoft Teams, Zoom Meetings, and web browser using Live Call Connect |
| Monitoring | Up to 4 multiviewer displays with configurable workspaces and viewports |
| Signal Monitoring | Integrated waveform and vectorscope with digital calibration, color preview, and ITU-R Rec. 709 support |
| Video Processing | YCbCr plus alpha color space using 4:2:2:4 processing |
| Audio Processing | Floating point, 96 kHz |
| Tally | Network tally via NDI with TSL 5 support |
| Networking | 1 x 10 GbE, 1 x 2.5 GbE, and 1 x 1 GbE |
| System Physical | 2RU chassis with redundant 550W power supplies; 19.0 x 3.5 x 19.57 in |
| Packaged Weight | 32 lb / 14.5 kg |
| Standard Support | 1 year standard support; upgrade options available |
What Is the TriCaster Vizion 0 SDI Live Production Switcher Used For?
This configuration is designed for multi-camera live production environments that use NDI and IP video rather than physical SDI production connections, including broadcast, sports, live events, enterprise media, education, and remote production.
How Many NDI Inputs Does TriCaster Vizion Support?
TriCaster Vizion supports 44 simultaneous IP video inputs via NDI. The network inputs are resolution-independent and support key and fill.
Does the 0 SDI I/O TriCaster Vizion Have Physical SDI Ports?
No. This hardware configuration has no physical SDI video I/O. Its production video workflow is centered on NDI and IP connectivity while retaining local monitoring, audio, USB, and network connections.
Does TriCaster Vizion Support UHD 4K NDI Production?
Yes. Compatible sources are supported up to UHD, including 2160p59.94, and the platform can provide up to two UHD video mix outputs.
How Many NDI Outputs Are Available in HD Workflows?
Vizrt specifies up to 56 IP outputs via NDI in HD sessions, supporting complex network routing, multiview, media, and production output workflows.
Which Remote Contribution Platforms Work with Live Call Connect?
Vizrt lists Microsoft Teams, Zoom Meetings, and browser-based video calls for Live Call Connect, with support for multiple simultaneous video-call inputs.
Is TriCaster Vizion AI/R Included with the Switcher?
TriCaster Vizion AI/R is an optional subscription that adds real-time AI-powered keying and augmented reality graphics.
What Vizrt Support Comes with TriCaster Vizion?
Vizrt specifies one year of standard support. Optional advanced hardware replacement is available, and support coverage can be upgraded.
Ready to Build an NDI-First TriCaster Vizion Production System?
Coremicro is an authorized Vizrt dealer for professional live production systems. Contact our team to confirm the Vizrt TriCaster Vizion 0 SDI I/O configuration, NDI network design, source bandwidth, storage workflow, control requirements, and facility integration.
