Product Highlights
- 8 Configurable SDI I/O Ports
- 16 NDI Inputs Up To UHD 4K
- M/E Switching, Keying, And Graphics
- 16-Channel Audio Mixer And 4TB Storage
- LivePanel Pro With Custom Controls
Vizrt TriCaster Prizm with 8 SDI
- SKU:
- TCPRIZM8SDI
- MPN:
- FG-003326-R001
Ships in 3-7 Business Day
Free Expedited Shipping
Secure payment
Manufacturer Warranty
Authorized Dealer
Product Inquiry Form
Description
Product Overview
Vizrt TriCaster Prizm with 8 SDI brings rackmount live production switching, NDI sources and configurable SDI connectivity into a single 2RU system. Work with 16 simultaneous external video sources at resolutions up to UHD 4K, and assign the eight SDI ports as inputs or outputs according to the production plan. Up to four of those ports support 12G-SDI signals. One production engine for the studio and remote contributors.
The Vizrt TriCaster Prizm 8-SDI configuration, manufacturer part FG-003326-R001, is a 2RU live production switcher sold by Coremicro, an authorized Vizrt dealer. The system supports 16 external inputs including NDI, SRT, RTMP, RTSP and WebRTC sources, and includes eight configurable SDI ports with up to four capable of 12G-SDI operation. It provides a 16-channel audio mixer, integrated M/E composition and keying, 4 TB of internal media storage, and LivePanel Pro browser-based control. Contact Coremicro for current pricing and manufacturer warranty details.
Browser-Based LivePanel Pro Production Control
LivePanel Pro supplies a customizable browser-based operating surface with low-latency previews, live feedback and role-based access. Build control pages around operator tasks instead of requiring every contributor to use the full switching interface.
Multi-Monitor Broadcast Production Workspaces
Four configurable multiviewer displays give directors and technical operators dedicated views of the production. Built-in waveform and vectorscope tools support critical picture checks during a live show.
Remote Contributor Video for Hybrid Events
Remote production support brings distant guests and network video feeds into the same switching workflow as local cameras. NDI, SRT, RTMP, RTSP and WebRTC input options make hybrid corporate events and distributed production more practical.
SDI Connections
8 configurable input/output ports; up to 4 ports support 12G-SDI
Network
10 GbE, 2.5 GbE and 1 GbE RJ-45 ports
System
2RU chassis with 500 W power supply
Live Sports Multi-Camera Switching
Combine stadium or venue SDI cameras with remote NDI sources, graphics and M/E compositions for a director-led program.
Worship Service Broadcast Production
Integrate local cameras, remote speakers, media playback and program feeds in a repeatable production workflow.
Hybrid Corporate Event Streaming
Switch in-room presenters and off-site contributors while giving operators browser-based production controls.
Broadcast Facilities
Engineers planning SDI and NDI signal paths.
Live Event Producers
Crews handling multiple local and remote cameras.
Education AV
Campus studios and student-led broadcast productions.
House of Worship
Teams running repeatable weekly productions.
Corporate Studios
Internal communications and hybrid event operators.
Vizrt Manufacturer Support
B&H lists a limited one-year manufacturer warranty for the FG-003326-R001 configuration. Confirm the current coverage and regional terms with Coremicro before ordering.
| Specification | Detail |
|---|---|
| SKU / manufacturer part number | TCPRIZM8SDI / FG-003326-R001 (8-SDI configuration) |
| Video Input | 16 simultaneous external video inputs; up to UHD 2160p59.94, 60 fps maximum |
| Network Video Input | Up to 16 NDI IP inputs, resolution-independent, with key and fill; SRT, RTMP, RTSP and WebRTC also supported |
| SDI Video Input | Up to 8 configurable HD-BNC SDI input/output ports supporting 12G/3G/HD-SDI; up to 4 ports support 12G signals |
| Supported SDI Input Formats | 2160p: 59.94, 50, 29.97, 25; 1080p: 60, 59.94, 50, 30, 29.97, 25; 1080i: 59.94, 50; 720p: 59.94, 29.97, 25. Available frame rates depend on NTSC/PAL session standard. |
| Video Output | Up to 4 independent 3G/HD mix outputs, or 2 UHD plus 2 3G/HD mix outputs; concurrent delivery over IP and SDI |
| Network Video Output | 36 NDI IP outputs in HD sessions only: 4 video mix outputs (up to 1080p60), up to 8 SDI-to-NDI direct outputs, 4 media-player outputs, 15 media-buffer outputs, 3 multiviewer outputs, 1 UI/dedicated multiviewer and 1 LiveStory Creator teleprompter output. Two UHD video mix outputs up to 2160p59.94 are specified separately. |
| SDI Video Output | Up to 4 independent 12G/3G/HD video mix outputs through configurable HD-BNC ports; rate depends on session standard |
| Audio | 16-channel integrated audio mixer with 8-channel audio support, DSP and 4x8x8 audio input routing |
| Local Audio Inputs | 1 balanced stereo pair (1/4-inch); 1 microphone input (1/4-inch); up to 8 SDI-embedded audio inputs |
| Local Audio Outputs | 1 balanced stereo pair (1/4-inch); 1 headphone output (1/4-inch); up to 8 SDI-embedded audio outputs |
| Network Audio | NDI audio input/output, including embedded audio; Dante via separately licensed Dante Virtual Soundcard; AES67 via compatible WDM audio driver and separately purchased third-party virtual sound card license |
| Media Players / Buffers | 5 media players (datasheet identifies 2 DDR and 1 Sound); 15 media buffers comprising 10 animation buffers with GIF support and 5 graphic buffers |
| Keyers | LiveMatte chroma/luma keying: 16 input keyers, 4 media player keyers, 4 M/E keyers, 1 PREVIZ keyer and 15 buffer keyers |
| COMPs | Integrated composition engine on switcher and each M/E bus; 16 configurable COMP presets per bus |
| Virtual Sets | LiveSet technology with 30+ live virtual sets and box effects |
| DataLink | Automated data input from webpages, spreadsheets, scoreboards, databases, RSS, watch files, XML, CSV, ASCII and other sources |
| Macros | Record, edit and automate production commands; buttons, shortcuts, hotspots, MIDI, X-keys, GPI, events and web controls |
| Recording | No software limit specified by manufacturer |
| Media Storage | 4 TB internal storage |
| System Drive | 250 GB |
| PTZ Control | Up to 16 simultaneous PTZ cameras; serial RS232/RS422 and IP control with presets |
| Conference Calling | Zoom, Teams NDI and web browser support |
| Grab / Export | Full-resolution deinterlaced still grabs; video/image export to social platforms, FTP, local/external volumes and network servers, with optional transcoding |
| Supported Media Files | Video: AVI, DV, DVCPro, DVCProHD, FLV, F4V, H.263, H.264, MOV, MKV, MJPEG, MPEG, MP4, WMV, WebM and more; images: PSD, PNG, TGA, BMP, JPEG, JPEG-XR, JPEG2000, EXR, RAW, TIF, WebP and more; audio: AIFF, MP3, WAV and more |
| Monitoring | Up to 4 multiviewer displays with configurable workspaces/viewports; 4 DisplayPort-connected outputs |
| Signal Monitoring | Integrated waveform and vectorscope; digital calibration, color preview and ITU-R Rec. 709 support |
| Processing | Video YCbCr + Alpha, 4:2:2:4; floating-point audio at 96 kHz |
| A/V Standards | 12G-SDI: SMPTE ST 2082; 3G-SDI: SMPTE 424M Level A; HD-SDI: SMPTE 292M |
| Tally | Network tally via NDI; TSL 5 support |
| Genlock | Genlock I/O board input for SD bi-level or HD tri-level reference |
| GPI / MIDI | JLCooper Electronics eBox GPI interface support; standard MIDI support |
| Network Interfaces | 1 x 10 GbE RJ-45; 1 x 2.5 GbE RJ-45; 1 x 1 GbE RJ-45 |
| USB Connections | 2 x USB 2.0; 5 x USB 3.2 Gen 2; 1 x USB 3.2 Gen 2x2 Type-C (5V/3A) |
| Chassis / Power | 2RU rackmount chassis with 500 W power supply |
| Dimensions | 19.0 x 3.5 x 19.57 in (48.3 x 8.9 x 49.7 cm) |
| Packaged Weight | 32 lb (14.5 kg), including packaging |
| Box Contents | Keyboard and mouse 3 x Mini DisplayPort-to-DisplayPort adapters 1 x Mini DisplayPort-to-HDMI adapter 9 x HD-BNC-to-BNC adapters Power cord |
What makes the Prizm 8-SDI configuration different?
This configuration includes eight configurable SDI ports. Up to four of those ports can carry 12G-SDI signals.
Can TriCaster Prizm mix SDI and NDI sources?
Yes. The production system accepts compatible SDI and NDI sources as part of its 16 simultaneous external inputs.
Does Prizm support remote video contributors?
Yes. IP input support includes NDI, SRT, RTMP, RTSP and WebRTC.
What does LivePanel Pro provide?
LivePanel Pro provides customizable browser-based control, live previews and role-based access for production teams.
How many 12G-SDI connections are supported?
Up to four of the eight configurable SDI ports support 12G signals. The ports are shared between input and output assignments.
Is Coremicro an authorized Vizrt dealer?
Coremicro is an authorized Vizrt dealer offering equipment sourcing and configuration support for professional AV production.
Configure Your 8-SDI Live Production Switcher
Coremicro is an authorized Vizrt dealer. Talk with our broadcast team about SDI port assignment, NDI network requirements, studio integrations and live event workflows for this specific configuration.
