Product Highlights
- 32-bit float mono recording
- LTC timecode input and output
- Bluetooth app control and monitoring
- Locking 3.5mm microphone input
Tentacle Sync TRACK E 32-Bit Float Timecode Audio Recorder Basic Box
- SKU:
- TEN-TR1-B-US
- MPN:
- TR1BUS
Ships in 1-3 Business Day
Free Expedited Shipping
Secure payment
Manufacturer Warranty
Authorized Dealer
Product Inquiry Form
Description
Product Overview
Tentacle Sync TRACK E Pocket Audio Recorder is a compact 32-bit float audio recorder built for audio-for-video workflows that need reliable timecode without a full-size field recorder. The Basic Box configuration provides the recorder unit for operators who want to choose their own compatible locking 3.5 mm lavalier microphone. Wired LTC input and output, wireless synchronization, Bluetooth app control, and 48 kHz mono recording make it practical for interviews, documentaries, multicamera shoots, and content production. Small recorder. Serious synchronization.
32-Bit Float Recording for Unpredictable Levels
32-bit float recording gives production crews substantially more level latitude when dialogue changes unexpectedly. Quiet material can be raised in post while loud moments are easier to recover than with conventional fixed-level recording. TRACK E also provides a 24-bit recording mode when smaller files are preferred.
Timecode Recorder for Audio-for-Video Production
LTC timecode support gives editors a common timing reference between separately recorded audio and video. TRACK E can receive timecode through its microphone connection and output LTC through its headphone connection for compatible synchronization workflows. Multiple Tentacle devices can also be synchronized wirelessly for multicamera and multi-recorder productions.
48 kHz Mono WAV and BWF Recording
Professional audio-for-video recording runs at a fixed 48 kHz sampling rate with WAV and BWF file support. A single mono recording track keeps the workflow straightforward for lavalier microphones, interviews, dialogue capture, and plant-mic applications. Files can be transferred to a computer through the USB-C connection.
Locking 3.5 mm Lavalier Microphone Input
The locking 3.5 mm microphone input provides a secure connection for compatible lavalier microphones during talent recording. Five-volt plug-in power supports suitable electret microphones without requiring a separate microphone power supply. The Basic Box is the recorder-only configuration, so the lavalier microphone can be selected separately for the production.
Bluetooth App Control and Wireless Timecode Sync
Bluetooth Low Energy connects TRACK E with the Tentacle Setup App on compatible iOS and Android devices. Operators can configure recorders, synchronize timecode, start or stop units, and monitor device status without reaching the talent. Apple Watch control is also supported for convenient multi-device operation.
USB-C Charging and Fast File Management
USB-C handles charging, card-reader access, firmware updates, and supported MIDI timecode operation. Connecting TRACK E directly to a computer provides a straightforward way to move recorded files without removing the memory card. The internal rechargeable battery supports extended location and production work between charges.
Wired LTC Timecode Input and Output
TRACK E can jam-sync from incoming LTC and can also act as a timecode source for compatible external equipment. Timecode input is handled through the microphone connection while output is available through the headphone connection. Timecode output is disabled while the unit is actively recording audio.
Wireless Multi-Recorder Synchronization
Multiple TRACK E recorders can be synchronized through the Tentacle ecosystem for dialogue and multitrack production. Once synchronized, each recorder maintains its timing reference independently rather than requiring a continuous Bluetooth connection. This makes distributed recording practical across talent, cameras, and remote positions on set.
Tentacle Setup App Remote Recorder Control
The Tentacle Setup App centralizes synchronization, configuration, record control, and status monitoring. A crew can manage multiple Tentacle devices from one supported mobile device instead of adjusting every recorder individually. Wireless audio monitoring is also available, although monitoring latency and stability depend on the connected smartphone.
Headphone Playback Monitoring in the Field
A dedicated 3.5 mm headphone connection supports playback monitoring after recording. This allows an operator to check captured dialogue before leaving a location or moving to another setup. The connector also performs timecode-output duties when TRACK E is being used as an LTC source.
Low-Cut Filter and Input Limiter
Built-in signal processing includes a low-cut filter for reducing unwanted low-frequency energy. A limiter is available in 24-bit recording mode to help control unexpected peaks. These tools are useful for spoken-word recording, documentary interviews, journalism, and other field-production situations.
Compact 58 g Bodypack Audio Recorder
At approximately 47 x 68 x 19 mm and 58 g, TRACK E is small enough for talent-worn recording and discreet plant-mic placement. The compact body reduces the amount of hardware carried on a presenter or hidden around a set. A belt-clip mounting system supports practical wearable installation.
Documentary Crews
Record isolated dialogue directly on talent while keeping sound synchronized with independently operated cameras.
Videographers
Add dependable audio-for-video recording to interviews, corporate productions, events, and multicamera shoots.
Journalists
Use a lightweight recorder for mobile interviews where a full field-recorder package would slow down the assignment.
Content Creators
Capture high-headroom dialogue without relying on a camera-mounted recorder or continuously monitored wireless link.
Location Sound Teams
Deploy TRACK E as a compact talent recorder, backup track, or plant recorder in demanding location-sound workflows.
Multicamera Productions
Keep independent audio recorders and compatible camera systems aligned through a shared timecode workflow.
| Format | Support |
|---|---|
| Recording Tracks | 1 mono track |
| Sample Rate | 48 kHz |
| Bit Depth | 32-bit Float or 24-bit |
| Audio File Format | WAV / BWF |
| Timecode Standard | SMPTE 12M LTC |
| Frame Rates | 23.98, 24, 25 / 50, 29.97, 29.97 DF, 30 / 60 fps |
| Specification | Detail |
|---|---|
| Product Type | Pocket mono audio recorder with timecode |
| Model | TRACK E Basic Box |
| Manufacturer Part Number | TR1-B-US |
| Recording Tracks | 1 mono track |
| Sampling Rate | 48 kHz |
| Recording Bit Depth | 32-bit Float / 24-bit |
| File Formats | WAV / BWF |
| Recording Time with 16 GB Card | Approximately 30 hours at 24-bit / 23 hours at 32-bit |
| Storage Media | microSDHC card up to 64 GB, Class 10 recommended |
| Microphone Input | Locking 3.5 mm jack |
| Microphone Plug-In Power | 5 V |
| Headphone Output | 3.5 mm dual-mono jack |
| Timecode Input | LTC via microphone input |
| Timecode Output | LTC via headphone output; output is disabled during recording |
| Wireless Synchronization | Bluetooth through Tentacle Setup App and Apple Watch |
| Bluetooth | Bluetooth 5.2 Low Energy |
| Remote Control | Tentacle Setup App for iOS and Android; Apple Watch support |
| Wireless Audio Monitoring | Via Bluetooth through Tentacle Setup App |
| USB Connection | USB-C, USB 2.0 |
| USB Modes | Charging, card reader, firmware update, MIDI timecode |
| Signal Processing | Low-cut filter; limiter in 24-bit mode |
| Frequency Response | 20 Hz to 20 kHz |
| Gain Range | +6 to +46 dB |
| Dynamic Range | 110 dB typical |
| THD+N | ≤ -85 dB / 0.05% |
| Battery | Built-in rechargeable lithium battery |
| Battery Runtime | Approximately 10 hours |
| Charging Time | Maximum approximately 2 hours |
| Dimensions | 47 x 68 x 19 mm / 1.85 x 2.67 x 0.74 in |
| Weight | 58 g / 2.0 oz |
| Mounting | Belt clip |
| Basic Box Configuration | Recorder unit; lavalier microphone sold separately |
Tentacle Sync Manufacturer Support
TRACK E carries a limited two-year manufacturer warranty. Tentacle Sync designs and manufactures its timecode equipment in Germany and provides troubleshooting, repair, and replacement support through its service network.
What is the Tentacle Sync TRACK E used for?
TRACK E is a compact mono audio recorder for audio-for-video production. It records dialogue independently from the camera while maintaining a timecode reference that simplifies synchronization during post-production.
Does the TRACK E Basic Box include a lavalier microphone?
No. The Basic Box is the recorder-focused configuration and does not include the lavalier microphone supplied with other TRACK E packages. It accepts compatible microphones through its locking 3.5 mm input with 5 V plug-in power.
Does TRACK E support 32-bit float audio?
Yes. TRACK E records mono audio at 48 kHz in either 32-bit Float or 24-bit mode. WAV and BWF file formats are supported for standard professional post-production workflows.
How does TRACK E timecode synchronization work?
TRACK E can receive LTC through its microphone input, output LTC through its headphone connection, or synchronize wirelessly through the Tentacle Setup App. Multiple Tentacle devices can therefore share a common time reference during a production.
Can TRACK E be controlled from a smartphone?
Yes. The Tentacle Setup App for iOS and Android provides remote configuration, synchronization, control, status information, and wireless audio monitoring. Compatible Apple Watch control is also supported.
What size memory card does TRACK E support?
The current manufacturer specification lists microSDHC cards up to 64 GB, with Class 10 media recommended. A 16 GB card provides approximately 30 hours of 24-bit recording or 23 hours of 32-bit recording.
What warranty comes with the Tentacle Sync TRACK E?
Tentacle Sync provides a limited two-year manufacturer warranty on TRACK E hardware. Warranty coverage begins from the qualifying purchase date and is supported through Tentacle Sync and its authorized service network.
Ready to Add TRACK E Timecode Recording to Your Production?
Coremicro is an authorized Tentacle Sync dealer supplying professional audio, timecode, camera, and production equipment. Contact our team to confirm microphone compatibility, timecode cabling, and the right Tentacle workflow for your cameras and post-production system.
