SONY Wireless Package with Handheld Mic with built-in Transmitter (25)

SONY Wireless Package with Handheld Mic with built-in Transmitter (25) is a camera-mount wireless handheld microphone system built for ENG, electronic field production, interviews, documentaries, weddings, and remote production work. From the supplied source, the package includes a Sony URX-P40 camera-mount wireless receiver and a Sony UTX-M40 wireless handheld cardioid microphone transmitter.

This is the kind of setup that makes sense when the talent, reporter, or presenter needs to move freely while the audio still lands back at the camera. The handheld transmitter keeps the microphone and wireless transmitter in one unit, while the URX-P40 stays compact on the camera side.

Highlights

• Wireless handheld microphone package for camera-mounted production workflows
• UC25 frequency range: 536.125 to 607.875 MHz
• UTX-M40 handheld transmitter with dynamic unidirectional capsule
• URX-P40 receiver with true diversity reception and OLED display
• NFC sync, USB-C power support, and adjustable output level

Quick Specs & Uses

• Receiver model: Sony URX-P40 portable camera-mount receiver
• Handheld transmitter: Sony UTX-M40 handheld microphone with unidirectional capsule
• Carrier frequency, UC25: 536.125 MHz to 607.875 MHz
• Receiver reception type: True diversity method
• Receiver antenna: 1/4 wavelength wire antenna, angle-adjustable
• Receiver display: OLED
• Receiver frequency response: 23 Hz to 18 kHz typical
• Receiver output adjustment: -12 dB to +12 dB, 3 dB steps
• Receiver audio output connector: 3.5 mm 3-pole locking mini jack
• Receiver headphone connector: 3.5 mm mini jack
• Receiver battery life: Approx. 6 hours with two LR6/AA alkaline batteries
• Receiver dimensions: 63 x 70 x 31 mm / 2 1/2 x 2 7/8 x 1 1/4 in, excluding antenna
• Receiver mass: Approx. 131 g / 4.6 oz, excluding batteries
• Handheld capsule type: Dynamic
• Handheld directivity: Uni-directional
• Handheld frequency response: 70 Hz to 18 kHz typical
• Handheld audio attenuator: 0 dB to 21 dB, 3 dB steps
• Handheld RF output power: 30 mW / 5 mW selectable for UC models
• Handheld maximum audio input level: 151 dB SPL
• Handheld battery life: Approx. 8 hours at 30 mW output power
• Handheld dimensions: ø48 x 258 mm / 1 15/16 x 10 1/4 in
• Handheld mass: Approx. 255 g / 9.0 oz, excluding batteries
• Power requirements: DC 3.0V with two LR6/AA batteries or DC 5.0V from USB Type-C connector

Why It Helps

This package is useful when the production needs a wireless handheld mic instead of a lavalier. For street interviews, press-style questions, presenter handoffs, or event coverage, the UTX-M40 gives the speaker a familiar handheld format while sending audio wirelessly to the camera-mounted URX-P40 receiver.

The dynamic unidirectional capsule helps keep the pickup focused toward the speaker. That is helpful in real field work where background noise, crowd sound, and room reflections can easily get into the mic if the operator has less directional control.

The URX-P40 receiver keeps the camera side simple. With adjustable output from -12 dB to +12 dB, the operator has room to match the wireless output to different camera inputs. NFC sync and OLED status displays also make setup quicker when the crew is moving between locations.

System Characteristics

• True diversity reception on the URX-P40 receiver for stable wireless capture
• UTX-M40 handheld transmitter with built-in wireless operation
• OLED displays for quick status checks on receiver and transmitter
• NFC sync for fast channel setting between transmitter and receiver
• USB-C power support for flexible receiver and transmitter powering

What’s In The Box

• 1 x Sony UWP-D22 Camera-Mount Wireless Cardioid Handheld Microphone System (UC25: 536 to 608 MHz)
• 1 x Sony URX-P40 Camera-Mount Wireless Receiver (UC25: 536 to 608 MHz)
• 1 x Sony UTX-M40 Wireless Handheld Cardioid Microphone Transmitter (UC25: 536 to 608 MHz)
• 1 x Mic Holder
• 1 x Belt Clip
• 1 x Sony SMAD-P4 Shoemount Adapter for URX-P40 Receiver
• 1 x 3.5mm to 3.5mm Output Cable
• 1 x 3.5mm to XLR-M Output Cable
