SONY Wireless Handheld Mic with Built-in Transmitter (90)

SONY Wireless Handheld Mic with Built-in Transmitter (90) is a wireless handheld microphone transmitter built for ENG, interviews, documentaries, weddings, remote production, and field audio work. From the supplied source, the Sony UTX-M40 uses a dynamic capsule, uni-directional pickup, and operates on the UC90 frequency range from 941.625 to 959.625 MHz.

This is a clean handheld option when the speaker needs to move freely without a cable running back to the camera or receiver. The transmitter is built into the microphone body, so the setup stays simple for reporters, presenters, and interview subjects.

Highlights

• Wireless handheld microphone transmitter for field and production use
• UC90 frequency range: 941.625 to 951.875 MHz, 953.000 to 956.125 MHz, and 956.625 to 959.625 MHz
• Dynamic unidirectional capsule for focused voice pickup
• 70 Hz to 18 kHz frequency response
• OLED display, NFC sync, USB-C power support, and audio attenuator control

Quick Specs & Uses

• Model: Sony UTX-M40 wireless handheld cardioid microphone transmitter
• Carrier frequency, UC90: 941.625 MHz to 951.875 MHz, 953.000 MHz to 956.125 MHz, and 956.625 MHz to 959.625 MHz
• Capsule type: Dynamic
• Directivity: Uni-directional
• Antenna type: 1/4 λ wavelength wire antenna
• Audio attenuator adjustment: 0 dB to 21 dB, 3 dB steps
• Audio delay: Approx. 0.35 ms
• Display: OLED
• Distortion: 0.9% or less
• Frequency response: 70 Hz to 18 kHz typical
• Maximum audio input level: 151 dB SPL
• RF output power: 30 mW / 5 mW selectable for UC models
• Reference audio input level: -55 dBV, gain mode set to normal, 0 dB attenuation
• Signal-to-noise ratio: 60 dB; 102 dB in AUTO GAIN max.; 96 dB in NORMAL max.
• Power requirements: DC 3.0V with two LR6/AA batteries or DC 5.0V from USB Type-C connector
• Battery life: Approx. 8 hours at 30 mW output power
• Dimensions: ø48 x 258 mm / 1 15/16 x 10 1/4 in
• Mass: Approx. 255 g / 9.0 oz, excluding batteries
• Operating temperature: 0°C to 50°C / 32°F to 122°F
• Storage / transport temperature: -4°F to 140°F / -20°C to +60°C

Why It Helps

The UTX-M40 is practical when a production needs a wireless handheld mic without adding a separate bodypack. For interviews, stand-ups, event coverage, and presenter work, it keeps the mic familiar for the person holding it and easier to manage for the operator.

The dynamic unidirectional capsule helps keep the pickup aimed toward the speaker. That matters in live locations, especially around crowd noise, room reflections, or outdoor ambience where the microphone needs to stay focused on speech.

Setup stays straightforward. The OLED display gives clear status feedback, NFC sync helps with fast channel setting, and USB-C power support gives another option for longer or more controlled production setups.

System Characteristics

• Built-in transmitter design keeps the handheld microphone cable-free
• Dynamic unidirectional capsule for focused speech capture
• Audio attenuator control from 0 dB to 21 dB in 3 dB steps
• NFC sync for quick channel setting with compatible receivers
• OLED display for clear status checking in indoor or outdoor work

What’s In The Box

• 1 x Sony UTX-M40 Wireless Handheld Cardioid Microphone Transmitter (UC90: 941 to 960 MHz)
• 1 x Microphone Holder
