SONY HXCU-FZ90 4K/HD Camera Control Unit for HXC-FZ90 Camera (Neutrik)

SONY HXCU-FZ90 4K/HD Camera Control Unit for HXC-FZ90 Camera (Neutrik) is a professional CCU designed for Sony HXC-FZ90 studio camera workflows. It provides camera power, video signal processing, remote control, intercom, tally, reference, trunk, and SDI output in a rack-ready control unit for studio and live production environments.

For broadcast engineers, the HXCU-FZ90 is useful when the camera needs to be placed far from the control room while still keeping stable video, power, communication, and control. With a Neutrik optical fiber camera connector and optional extension support, it fits well in sports venues, studios, worship facilities, campuses, and larger live production systems.

Highlights

• 4K/HD camera control unit for Sony HXC-FZ90 camera systems
• Neutrik optical fiber camera connector for professional camera-to-CCU connection
• Supports 12G-SDI, 3G-SDI, HD-SDI, and SD-SDI output workflows
• Long-distance optical fiber extension up to 6.21 miles / 10 km with optional extension unit
• Intercom, tally, LAN, trunk, reference, and remote control support
• Optional 4K and HDR workflow expansion with BT.2020, HLG, and S-Log3 support

Quick Specs & Uses

• Product type: 4K/HD camera control unit
• Compatible camera: Sony HXC-FZ90 studio camera
• Camera connector: Neutrik optical fiber connector x1
• Fiber cable support: Single-mode LC / CCFN
• Maximum distance: 6.21 miles / 10 km
• Power supply maximum distance: 984.3 ft / 300 m
• AC input: 100 V to 240 V AC
• Remote: 8-pin x1
• LAN: RJ-45 x1
• Trunk: 12-pin x1 and RJ-45 x1
• Intercom front panel: 4-pole mini jack
• Intercom / program / tally: DB-25, red and green tally / preview out
• Reference input: BNC x2, HD and SD support
• Prompter input / output: BNC x2, loop-through
• Video output: 3G / HD / SD-SDI BNC x4; 12G / 6G / 3G / HD-SDI BNC x2
• Character display output: BNC x1
• Audio output: Channel 1 and Channel 2, 3-pin XLR x2
• Audio output level: 0 / -20 dBu / +4 dBu

Why It Helps

The HXCU-FZ90 gives production teams a practical way to run the HXC-FZ90 as part of a studio-style camera chain. It keeps camera power, video return, control, tally, intercom, and signal output centralized at the CCU position, which makes the system easier to manage during live work.

The Neutrik optical fiber connection is useful for long camera runs. In large venues or remote camera positions, the CCU can carry high-quality signal over long distances while still maintaining the control and communication features needed for broadcast operation.

The SDI output section also gives engineers flexibility. With support for 12G-SDI, 6G-SDI, 3G-SDI, HD-SDI, and SD-SDI formats, the unit can fit both modern 4K systems and existing HD infrastructure.

System Characteristics

• Multi-format output for UHD 4K, Full HD, and SD production environments
• Multi-frame-rate support for broadcast and live production standards
• Optional 4K / HDR expansion for BT.2020, HLG, and S-Log3 workflows
• Reference input for system sync and timing integration
• Intercom and tally support for live studio operation
• Prompter loop-through for studio camera setups
• LAN and trunk connectivity for system control and auxiliary communication
• Audio output support through dual 3-pin XLR connectors

What’s In The Box

• 1 x Sony HXCU-FZ90 4K/HD Camera Control Unit for HXC-FZ90 Camera (Neutrik)
• 1 x Tally Number Plate Set (0–9)
