RGBLINK MSP 331U Gen2 HDMI 2.0 4K60 Capture Card

RGBLINK MSP 331U Gen2 HDMI 2.0 4K60 Capture Card is the kind of device you use when you need to get a clean HDMI signal into a computer without turning the workflow into a software problem. Built as a plug-and-play capture interface, it takes in high-resolution HDMI video and hands it off to the host computer over USB-C 3.2 for streaming, recording, and general capture workflows.

Highlights

• Captures video from HDMI sources for recording and live streaming workflows
• Supports up to UHD 4K60 with RGB 4:4:4 8-bit input support
• USB-C 3.2 output to computer with 5 Gb/s data transfer
• 3.5 mm analog audio input adds flexibility for commentary or external audio feeds
• Plug-and-play UVC/UAC operation supports Windows, macOS, and Linux

Quick Specs & Uses

• Capture type: HDMI 2.0 to USB-C 3.2
• Maximum supported capture resolution: 3840 x 2160 at 60 Hz
• Color support: RGB 4:4:4 8-bit
• HDR support: yes
• Audio input: 3.5 mm analog audio input
• Data transfer rate: 5 Gb/s
• Compliance: HDCP 2.3, UVC 1.5, UAC 1.0
• Supported formats: RGB24, YUY2, P010, NV12, I420
• Platform compatibility: Windows, macOS, Linux

Why It Helps

In real capture workflows, the challenge is not just getting signal into the computer. It is getting it there cleanly, reliably, and without creating driver or software headaches. The RGBLINK MSP 331U Gen2 is useful because it keeps the capture path standards-based, supports modern UHD formats, and adds analog audio flexibility for workflows that need more than embedded video alone.

System Characteristics

• 4K60 HDMI ingest keeps the device relevant in modern UHD capture workflows
• USB-C 3.2 interface gives the host computer a direct, high-bandwidth handoff
• Plug-and-play standards support reduces reliance on proprietary drivers
• Analog audio input helps support voiceover and external audio capture paths
• Multiple supported video formats make the unit easier to use across different software environments

What’s In The Box

Please refer to the Specifications tab for the exact included items.
