RGBLINK mini-pro v3 Switcher

RGBLINK mini-pro v3 Switcher is the kind of compact switcher you use when the production is small but the workflow still needs to feel complete. Built as a desktop live production unit, it combines 4 x 4K60 HDMI inputs, dual HDMI outputs, touchscreen control, USB streaming/recording, and PTZ handling in one portable chassis.

Highlights

• Compact HDMI live production switcher for smaller studio and event workflows
• 4 x HDMI 2.0 inputs supporting up to 4K60
• Dual HDMI outputs for preview, program, or AUX monitoring
• Built-in 2.1-inch IPS touchscreen for video preview and touch-menu operation
• PTZ control, PiP, chroma key, streaming, and USB recording in one unit

Quick Specs & Uses

• Inputs: 4 x HDMI 2.0
• Maximum input resolution: up to DCI 4K60
• Outputs: dual HDMI 1.3 outputs, USB-A output
• Streaming: up to 1080p60
• Display: 2.1-inch IPS touchscreen
• Transitions: 15 effects, including AUTO and WIPE
• Video tools: multi-view, PGM display, PiP, chroma key, pixel-to-pixel scaling
• Audio: 4-channel HDMI embedded plus 2-channel external audio mix
• PTZ: 5-axis joystick, preset save/load, one-click recall, IP VISCA support
• Network: RTMP(S) streaming, RJ45 LAN control, TAO Cloud support
• Power: USB-C

Why It Helps

In smaller production environments, the challenge is usually not just switching sources. It is finding one device that can also help with monitoring, streaming, PTZ control, recording, and basic compositing without forcing the workflow into multiple separate boxes. The RGBLINK mini-pro v3 is useful because it pulls those roles together in a package that still fits on a small desk.

System Characteristics

• 4-input HDMI design supports compact multi-source production workflows
• Touchscreen plus physical controls balance fast setup with hands-on operation
• USB output and one-key recording help support streaming and capture workflows
• PTZ, PiP, and chroma key tools make the switcher more useful than a simple source selector
• LAN and cloud support extend the unit into more connected control environments

What’s In The Box

Please refer to the Specifications tab for the exact included items.
