RGBLINK D8 PLUS 8K Splicer 1-Channel HDMI 2.1 Input Interface and 1-Channel DP 1.4 Input Interface

RGBLINK D8 PLUS 8K Splicer is the kind of processor you use when the job has already moved beyond ordinary switching and into serious canvas management. Based on the source, this is an 8K-capable native video scaler built with 1 x HDMI 2.1 input, 1 x DP 1.4 input, and 4 x HDMI 2.0 outputs, supporting up to 7680 x 4320 at 60 fps input and up to 4096 x 2160 at 60 fps output.

Highlights

• 8K60 input support for high-resolution source handling
• 1 x HDMI 2.1 input and 1 x DP 1.4 input for modern high-bandwidth source connectivity
• 4 x HDMI 2.0 outputs for downstream display delivery
• Genlock input and loop-through for synchronized system operation
• Multiple splicing layouts, layer cropping, and scaling for flexible display canvas control

Quick Specs & Uses

• Processor type: 8K native video scaler / splicer
• Input resolution support: up to 7680 x 4320 at 60 fps
• Output resolution support: up to 4096 x 2160 at 60 fps
• Inputs: 1 x HDMI 2.1, 1 x DP 1.4
• Outputs: 4 x HDMI 2.0
• Compliance: HDCP 2.2
• Display control: built-in 4-inch LCD touchscreen
• Processing functions: 8K EDID management, layer cropping, scaling, unequal splicing, multiple layout support
• Control: XPOSE 2.0, Open API
• Additional features: hot swap, genlock input and loop-through, custom output resolution support

Why It Helps

In large-format display systems, the real challenge is not just accepting a high-resolution signal. It is turning that signal into something that fits the canvas, stays synchronized, and remains controllable inside a larger system. The RGBLINK D8 PLUS is clearly built for that role. It takes in high-bandwidth source formats, provides splicing and scaling control, and gives the installer a more disciplined way to manage complex display layouts.

System Characteristics

• 8K input capability helps the processor accept very high-resolution sources at the front end
• 4-output HDMI architecture supports downstream multi-display or spliced display environments
• Genlock support helps keep the system aligned in timing-sensitive installations
• Touchscreen, software, and API control give the processor both local and integrated control options
• Custom resolution and layout flexibility make it easier to match the processor to real display canvases instead of forcing the canvas to match the processor

What’s In The Box

Please refer to the Specifications tab for the exact included items.
