Panasonic WX-SZ200 Wireless Microphone Desktop Charging Station

Panasonic WX-SZ200 is a compact 2-port charger built for keeping AA Ni-MH batteries ready without slowing the day down. It’s rated for an approx. 6-hour charge time at 77°F (25°C) using BK-3MCCA AA Ni-MH cells, and it includes a clear front-panel status with Power and charging error indicators per port. The unit runs from AC 120 V, 60 Hz, and ships with a DC 12 V AC adapter.

Highlights

• 2 charging ports for maintaining two AA Ni-MH batteries at once
• Approx. 6-hour charging time (77°F / 25°C, using BK-3MCCA AA Ni-MH)
• Per-port error indication so you can spot a problem battery quickly
• Low power draw with consumption up to 5 W
• AC powered with an included DC 12 V adapter for simple bench or rack-room use

Quick Specs & Uses

• SKU: WX-SZ200
• Charging ports: 2
• Charge time reference: approx. 6 hours at 77°F (25°C) using AA Ni-MH BK-3MCCA
• LED indicators: Power, charging error (per charge port)
• Operating ambient: 41 to 95°F (5 to 35°C)
• Power consumption: up to 5 W
• Power source: AC 120 V 60 Hz (AC adapter, DC 12 V included)
• Main unit size/weight: 7-7/8 x 3-35/64 x 4-11/64 in (200 x 90 x 106 mm) / 0.99 lb (450 g)
• AC adapter size/weight: 4-11/32 x 1-17/64 x 2-1/16 in (110.5 x 32.2 x 52.5 mm) / 0.37 lb (166 g)
• Warranty (parts/labor): 3 years

Why It Helps

Battery management is one of those small things that can quietly derail a production day. WX-SZ200 keeps the routine predictable: two ports, a defined charge-time reference under standard conditions, and a clear per-port error indicator so you can troubleshoot quickly instead of guessing which battery is the culprit.

System Characteristics

• Use within the rated 5 to 35°C ambient range to match the published charging reference
• Per-port error indication helps isolate a bad or problematic cell faster
• At up to 5 W, it’s an easy add to a bench, rack, room, or prep cart power strip
• Keep the AC adapter accessible since the unit is specified as AC powered, with a DC 12 V adapter included
• Compact footprint makes it practical for shared tech benches and prep areas

What’s In The Box

• 1 x Panasonic WX-SZ200 Wireless Microphone Desktop Charging Station
• 1 x AC Adapter
• 1 x Power Cord
