Panasonic WX-SR202DN 2-Channel Dante Digital Wireless Mic Receiver

Panasonic WX-SR202DN is a 2-channel digital wireless microphone receiver built around Dante for networked audio systems, with a practical analog fallback for mix output via Euroblock. From the specs provided, Dante supports Primary & Secondary paths with CH1/CH2/MIX available, while the Euroblock path is MIX only at -10 dBV balanced 600 ohms. It also supports an 8x RJ45 antenna connection scheme using straight CAT5/CAT5e/CAT6 cable runs up to 656 ft (200 m).

Highlights

• 2-channel receiver with Dante (RJ45) output for network audio workflows
• Dante Primary & Secondary paths with CH1/CH2/MIX availability
• Euroblock mix output (MIX only) at -10 dBV balanced 600 ohms
• 8x RJ45 antenna connectors with up to 200 m wiring distance using straight CAT cable
• Rack-ready with rack ears included and a front-panel status display for RF and audio monitoring

Quick Specs & Uses

• Model / SKU: WX-SR202DN
• Channel output circuits: 2
• Channel output connectors: Dante (RJ45), Euroblock (mix output only)
• Channel output characteristics: Dante Primary & Secondary (CH1/CH2/MIX); Euroblock (MIX only) @ -10 dBV balanced 600 ohms
• Channel output SNR: 70 dB or greater
• Channel output frequency response: 50 Hz to 15 kHz
• Audio input characteristics: -10 dBV balanced 600 ohms
• Audio input frequency response: 50 Hz to 15 kHz
• Audio input distortion: less than 3%
• Mix output connectors: Dante Primary & Secondary or Euroblock
• Mix output characteristics: Dante Primary & Secondary or Euroblock @ -10 dBV balanced 600 ohms
• Mix output SNR: 64 dB or greater
• Mix output distortion: less than 3%
• Antenna connectors: 8 x RJ45 (CAT5/CAT5e/CAT6 straight), wiring distance up to 656 ft (200 m)
• Antenna field selection: 4 ranges via DIP switches (front panel) or Panasonic Operations Support software
• Display indicators: Power, Antenna 1-8, Sync, Main, Remote, RF Level (5-level), Audio level/mute, Mic battery, Register
• Power: AC 120 V 60 Hz
• Power consumption: 39 W
• Operating ambient: 32 to 113°F (0 to 45°C)
• Dimensions (W x H x D): 16-17/32 x 1-47/64 x 9-27/32 in (420 x 44 x 250 mm)
• Weight: 6.39 lb (2.9 kg)
• Warranty (parts/labor): 3 years
• Accessories included: rack ears

Why It Helps

In a real facility or campus install, the receiver is only “easy” if it plays nicely with the rest of the system. WX-SR202DN leans into that by putting Dante front and center, including Primary/Secondary paths and channel plus mix availability. And when you need a simple analog handoff for a mix feed, the Euroblock MIX-only output keeps that option on the table without complicating the rack layout.

System Characteristics

• Use Dante Primary & Secondary when you want a cleaner networked path with CH1/CH2/MIX availability
• Plan the analog handoff correctly: Euroblock is listed as MIX only at -10 dBV balanced 600 ohms
• The front-panel display calls out Antenna 1-8 and a 5-level RF meter, which helps quick-check RF health during troubleshooting
• Antenna runs are spec’d up to 200 m using straight CAT5/CAT5e/CAT6, so cable planning can be done like an install, not a patch job
• Antenna field selection can be set via front-panel DIP switches or Panasonic’s Operations Support software

What’s In The Box

• 1 x Panasonic WX-SR202DN 2-Channel Dante Digital Wireless Mic Receiver
• 1 x Rack Ears Set
