Panasonic AW-UE5 4K Smart EPTZ with NDI (Black)

Panasonic AW-UE5 4K Smart EPTZ with NDI (Black) is a compact integrated camera designed for corporate spaces, classrooms, remote learning, event streaming, and multi-camera production. Its fixed ultra-wide lens provides a 121° horizontal field of view, allowing the camera to cover broad rooms and presentation areas without relying on mechanical pan-and-tilt movement.

AI-based Group Framing analyzes the scene and automatically adjusts the digital framing to follow the situation. The camera supports 4K video, HDMI, USB webcam operation, PoE, LAN control, and multiple IP streaming formats, including NDI|HX2 and NDI|HX3, making it suitable for installations that need automated camera work with minimal staffing.

Highlights

• Ultra-wide 121° horizontal field of view captures large rooms, groups, and presentation spaces
• AI-powered Group Framing automatically adjusts digital pan, tilt, and zoom around the detected group
• 4K HDMI and IP output supports professional recording, streaming, and production workflows
• NDI|HX2 and NDI|HX3 support provides flexible network-based video transport
• Single-cable PoE operation simplifies installation by carrying power and network connectivity through Ethernet

Quick Specs & Uses

• Product type: Compact 4K smart ePTZ camera
• Body color: Black
• Primary workflows: Corporate video, education, remote classes, event streaming, conferencing, and multi-camera production
• Image sensor: 1/2.8-inch MOS
• Lens: F2.4, 1.64mm
• 35mm equivalent focal length: 11.1mm
• Digital zoom: Up to 5x
• Horizontal field of view: 121° with electronic distortion correction off
• Vertical field of view: 86.5° with electronic distortion correction off
• Diagonal field of view: 129° with electronic distortion correction off
• Focus: Single focus
• Focus distance: 700mm
• HDMI output resolution: Up to 4K
• HDMI output connector: HDMI
• HDMI horizontal resolution: Approximately 1,400 TV lines in 4K and 900 TV lines in HD
• Gain control: Auto or 0 to 42dB in 3dB steps
• Shutter modes: Full Auto with Slow Shutter, Shutter Priority, and Manual
• White balance: ATW, AWB A, AWB B, 3200K, and 5600K
• Chroma adjustment: 11 steps from 0 to 10
• Built-in microphone: Stereo
• Audio controls: Mute and automatic level control
• LAN connection: RJ45 for IP control and streaming
• USB connection: USB-C
• USB webcam standard: USB Video Class 1.1
• USB video formats: YUV and MJPEG
• USB YUV resolutions: 1280 x 720 and 640 x 360
• USB MJPEG resolutions: 3840 x 2160, 1920 x 1080, 1280 x 720, and 640 x 360
• USB audio: Linear PCM, 48kHz, 16-bit, 2-channel
• IP video formats: MJPEG, H.264, H.265, NDI|HX2, and NDI|HX3
• Streaming protocols: HTTP, RTSP, RTMP, and RTMPS
• Maximum H.264/H.265 resolution: 3840 x 2160
• IP audio: AAC-LC, 48kHz, 16-bit, 2-channel
• Installation: Desktop or suspended mounting
• Manual pan range: ±110°
• Manual tilt range: ±25°
• Compatible controllers: AW-RP200GJ, AW-RP150GJ, AW-RP60GJ, and AW-RM50AG
• Power requirements: 5V DC through USB or 37V to 57V through PoE
• Current consumption: 3.0A through USB or 0.3A through PoE
• Operating temperature: 0°C to 40°C
• Operating humidity: 20% to 90% without condensation
• Storage temperature: -20°C to 50°C
• Dimensions: 123 x 131 x 139mm, excluding protrusions and mounting bracket
• Weight: Approximately 0.5kg, excluding mounting bracket

Why It Helps

The AW-UE5 is useful where a conventional PTZ camera would require more space, cabling, or active operation. Its ultra-wide lens can show an entire room, while digital pan, tilt, and zoom create tighter compositions from the 4K image without physically moving the camera.

AI Group Framing reduces the amount of manual camera work required during meetings, classes, and presentations. Combined with PoE, HDMI, USB webcam output, and NDI-compatible IP streaming, the camera can serve traditional AV, conferencing, and networked production workflows from the same compact installation.

System Characteristics

• Electronic PTZ architecture creates reframed shots from the wide 4K image without mechanical camera movement
• AI-assisted framing automatically adapts composition to groups and activity within the scene
• Multi-interface operation combines HDMI, USB-C, LAN, PoE, and IP streaming connectivity
• Network production support includes NDI|HX, H.264, H.265, RTMP, RTMPS, RTP, and RTSP workflows
• Flexible installation design supports desktop, suspended, remotely controlled, and single-cable deployments

What’s In The Box

• 1 x Panasonic AW-UE5 4K Smart EPTZ with NDI (Black)
