Product Highlights

4 RU KAIROS live video production mainframe for control-room workflows
Supports HDMI, SDI, and NDI processing options
ST 2022-7 redundant 1Gb networking for encoding and playback
Transport protocols include NDI/HX, RTMP, RTMPS, RTP, RTSP, and SRT
400 GB internal storage plus dual IEC C14 AC inputs (100 to 240 VAC at 10 A)

Panasonic KAIROS KC200 Core Flagship Mainframe

SKU:: AT-KC200P
MPN:: AT-KC200P

Special Order

Regular price $70,201.40

Add to Wishlist Enquiry

Ships in 3-7 Business Day

Free Expedited Shipping

Secure payment

Manufacturer Warranty

Authorized Dealer

Description

Product Overview

Panasonic KAIROS KC200 Core Flagship Mainframe (AT-KC200P) is a 4 RU control-room mainframe that runs the KAIROS live video production system. It is positioned for flexible, scalable workflows for live events, sports, and remote streaming, with input and output processing options noted for HDMI, SDI, and NDI, plus ST 2022-7 redundant 1Gb network ports for encoding and playback.

Highlights

KAIROS live production mainframe in a rack-ready 4 RU chassis
Cloud-based workflow focus with updated hardware noted on the page
HDMI, SDI, and NDI input and output processing options
ST 2022-7 redundant networking for encoding and playback
Up to 2 hours of HD video playback is listed in key features

Quick Specs & Uses

Other I/O: 2x RJ45 for Control, LAN, and NDI input/output
Transport protocols: NDI/HX, RTMP, RTMPS, RTP, RTSP, SRT
Internal storage: 400 GB
Power: 2x IEC C14 input (100 to 240 VAC at 10 A)
Form factor: 4 RU, 19.9 x 16.9 x 6.9 inches, 37.5 lb

Why It Helps

This mainframe is aimed at productions that need flexible routing, mixed-format workflows, and a clean path between baseband and IP transport. The overview calls out Agile Input Routing with flexible GPU I/O bandwidth allocation, a resolution-independent platform supporting up to 4K, and redundant power supplies to support continuous uptime.

System Characteristics

Designed for control-room and event workflows where flexible input and output handling matter
Agile Input Routing is described as allocating GPU I/O based on source bandwidth.
Resolution-independent operation supports up to 4K, with mixed resolutions and formats noted.
Protocol support includes NDI/HX plus common streaming and transport options like SRT and RTMP family.
Built-in redundant power supplies are noted to support continuous uptime

What’s In The Box

1 x Panasonic KAIROS KC200 Core Flagship Mainframe

Trusted Seller

Coremicro ships fast from the U.S. and supports this gear with a team that actually works with production systems.

Product Specifications
Video Inputs	ST 2110: 1.5G: 64 in 2 3G: 32 in 2 4K: 8 in 2 ST 2022-7 Redundancy:* No halving of input 2 SDI:* 1.5G: Max. 32 in 2 3 3G: Max. 32 in 2 3 4K: Max. 16 in 2 3 NDI® High Bandwidth (HD only): 2 in, 16 CH audio for each SRT / RTSP / RTP / RTMP (HD only): 8 in (only input for RTSP) *Foot note: Misc Specs
Audio Inputs	Audio Format: ST 2110-30 (AES67): 48 kHz/24 bit NDI® High Bandwidth (HD only): 16 CH audio for each Streaming IP: SRT/RTSP/RTP/RTMP
Video Outputs	ST 2110: 1.5G: 40 out 2 3G: 40 out 2 4K: 10 out 2 ST 2022-7 Redundancy:* Halving of output 2 SDI:* 1.5G: 16 out 2 3 3G: 16 out 2 3 4K: 8 out 2 3 NDI® High Bandwidth (HD only): 2 out, 16 CH audio for each SRT / RTP / RTMP (HD only): 2 out *Foot note: Misc Specs
Audio Outputs	Audio Format: ST 2110-30 (AES67): 48 kHz/24 bit NDI® High Bandwidth (HD only): 16 CH audio for each Streaming IP: SRT/RTSP/RTP/RTMP
Video Standards	Video Format: 4K: 2160/60p, 59.94p, 50p, 30p, 29.97p, 25p, 24p, 23.98p FHD: 1080/60p, 59.94p, 50p, 30p, 29.97p, 25p, 24p, 23.98p HD: 1080/59.94i, 50i, 720/60p, 59.94p, 50p Signal Processing: Y/PB/PR, 4:2:2 10 bit Color Model and Bit Depth: Y/PB/PR, 4:2:2 10 bit
Product Specific	Synchronization PTP Sync: QSFP and GbE, both ports supported Frame Synchronizer (FS): All input channels, always ON (no ON/OFF option) Frame Delay: 0 to 12 frames, adjustable in 1-frame steps Latency: Minimum 1 frame Multiviewer & Canvas Multiviewer Output: HD / 4K x 4 out, up to 36 PiP per output Canvas: Up to 8K (32 M-pixels) Layer & Processing Number of Layers, Scenes (ME) and Keys: No restriction; dependent on GPU performance Visible usage via GPU meter Tally & External Device Support 6-Color Independent Tally Indicators: ✔ NDI® Tally: ✔ Supported Tally Protocol: ✔ TSL 5.0 Compatible with Panasonic PTZ Camera and AK-UC4000 4K Studio Camera Compatible External Tally Box: ✔ Connectable Control Panel: Up to 16 units (AT-KC10C1G or AT-KC10C2G, each supports up to 8 units) PTZ Control of Panasonic PTZ Camera: ✔ Supported Standards & Protocols REST API: ✔ Command table available from PASS KAIROS website Ross Talk5: ✔ Optional AT-SFE01 required TSL 5.0:* ✔ *NMOS6: ✔ Optional AT-SFE03 required AMP (Advanced Media Protocol): ✔ ST 2110: ST 2110-10, ST 2110-20, ST 2110-30 Common Features (All Models) Effects: Luminance Key, Chroma Key, DVE (2D / 2.5D), Soft Border, Corner Fix, Color Correction, Crop Transition: Multimix, Offset Transition, Transition Effects Macro: Scene-Specific Macros, LUA Script Support Color Mat: Bicolor Wash Mat, Test Pattern Other Functions:** Audio Mixer 7 Title Generator Snapshot Multiviewer Display (GPU Meter, Audio Level Meter, Clock, etc.) User Management Function 2 Footnote Descriptions 1. Requires software version 1.7 or later. 2. Requires software version 1.6 or later. 3. Optional AT-KC20M1 SDI I/O boards are required. Each board provides 8 input terminals, 4 output terminals, and REF IN/OUT (maximum 8 inputs / 4 outputs in FHD/HD). Up to four boards can be installed in the AT-KC2000/200 and up to two boards in the AT-KC2000S1. The input/output numbers shown represent the maximum capacity when fully equipped. Installation must be performed by a dealer. Always consult your dealer for installation. 4. The maximum RAM Player capacity is reduced when SDI I/O boards are installed, as shown below: SDI I/O Boards Installed: Not installed 1 board 2 boards 3 boards 4 boards AT-KC2000: 96GB / 93GB / 90GB / 87GB / 84GB AT-KC2000S1: 86GB / 83GB / 80GB / – / – AT-KC200: 32GB / 31GB / 30GB / 29GB / 28GB AT-KC200L1: – / – / – / 32GB / 32GB 5.RossTalk, Ross, and XPression are registered trademarks of Ross Video Limited. 6.NMOS (Networked Media Open Specifications) is a protocol standardized by AMWA (Advanced Media Workflow Association) for controlling and managing devices via IP networks. 7.Optional AT-SF005 is required.
Media	Player Still Store: 7 GB storage, up to 4K RAM Player (Uncompressed): 8 CH, 32 GB storage 4 Clip Player (Compressed): 2 CH, 400 GB storage (shared with Audio Player) Supported formats: AVC-Intra / H.264 / DNxHD / ProRes Audio Player (Compressed):* 4 CH, 400 GB storage (shared with Clip Player) Supported formats: WAV / MP3 / Ogg / FLAC / AIFF
Operating Systems	Linux
Power Specifications
Power I/O	Power Requirement: AC IN x2, 100–127 V / 200–240 V, 50/60 Hz Current Consumption: 10.0 A / 5.0 A
Physical / Environmental Specifications
Dimension	Dimensions (W x H x D) 430 mm × 176 mm × 505 mm / 16-15/16" x 6-15/16" x 19-7/8" Weight, without accessories & options Approx. 17 kg / 37.47 lb Rack Mount Size 4 RU
Environment	Current Consumption: 10.0 A / 5.0 A Operating/Storage Temperature: 5 to 35 ˚C / –20 to 60 ˚C Operating Humidity: 10% to 90%, no condensation
Warranty	1-Year Manufacturer Warranty
