AJA OG-Hi5-12G-R-ST OpenGear 4K 12G-SDI to HDMI 2.0 Converter Card with Fiber ST Connector

AJA OG-Hi5-12G-R-ST OpenGear 4K 12G-SDI to HDMI 2.0 Converter Card with Fiber ST Connector is an openGear converter card built for one common reality in pro racks: your plant is SDI, but your monitoring is HDMI. It takes a 12G-SDI BNC or ST fiber input and outputs HDMI 2.0b for clean 4K/UHD viewing, with a reclocked 12G-SDI loop out so you can keep the SDI line moving downstream.

Highlights

• 12G-SDI to HDMI 2.0b conversion for 4K/UHD monitoring on HDMI displays
• ST fiber receiver input plus 12G-SDI BNC input for flexible plant integration
• Reclocked SDI loop out for pass-through pipelines and confidence paths
• HDR workflows supported with HDR10 metadata generation and HLG over HDMI
• Dashboard control for configuration and status in openGear environments

Quick Specs & Uses

• Video In: 1x 12G-SDI (BNC) and 1x ST Fiber
• Video Out: 1x HDMI 2.0b and 1x 12G-SDI (BNC loop)
• Embedded audio: SDI 16-channel to HDMI 8-channel, with adjustable delay (0–7 frames)
• Format support includes DCI 4K, UHD, 2K, and HD/SD formats up to 60p
• Power/Env: 13 W, operating 0–40°C, storage -40–60°C

Why It Helps

If you need to watch an HDR-capable 12G feed on an HDMI display without breaking the SDI path, this card is the clean rack answer. You get HDMI monitoring for 4K/UHD, while the reclocked loop out keeps the SDI pipeline intact for routing, downstream monitoring, or additional destinations.

What’s In The Box

Package contents vary by configuration. Please refer to the Specifications tab for the exact included items.

Trusted Seller

Coremicro ships from the U.S. and supports this gear with a team that actually works with SDI racks, fiber runs, and openGear systems.
