NETGEAR M4350-24F4V 24-Port 10G SFP+ Managed AV Network Switch

NETGEAR M4350-24F4V 24-Port 10G SFP+ Managed AV Network Switch is built for AV and broadcast network environments where dense fiber connectivity, uplink headroom, and predictable traffic handling matter more than PoE. Based on the source details, this switch provides 28 total ports, including 24 x 10G SFP+ ports and 4 x 25G SFP28 ports, making it a strong fit for media transport, aggregation, and fiber-based switching workflows.

Highlights

• 24 x 10G SFP+ ports for dense optical connectivity
• 4 x 25G SFP28 ports for higher-bandwidth uplinks and aggregation
• Enhanced IGMP support, AVB included, and jumbo frames up to 12kb
• No PoE budget, positioning the switch for fiber transport rather than powered edge access
• Quiet Mode acoustics rated at 34.2 dB at 25°C

Quick Specs & Uses

• Width: 440 mm
• Depth: 400 mm
• Height: 43.2 mm
• Weight: 6.25 kg (13.78 lb)
• Primary port speed: 10 Gigabit
• Number of ports: 28 (24 x 10G SFP+, 4 x 25G SFP28)
• PoE ports / budget: N/A
• IGMP support: Enhanced (NETGEAR IGMP Plus)
• Jumbo frame support: Yes, up to 12kb
• AVB support: Yes, included
• Acoustics: Quiet Mode 34.2dB @ 25°C
• Power consumption: 119.3W / 374.6Btu/hr; standby without any port connection: 45.2W / 141.93Btu/hr
• PSU compatible models: APS350Wv1, APS600Wv2, APS920Wv1, APS2000Wv1

Why It Helps

In higher-performance AV and broadcast systems, not every switch is there to power endpoints. Some are there to move media traffic cleanly and predictably across a fiber-heavy network. The M4350-24F4V fits that role well, combining dense 10G optical connectivity, 25G uplink headroom, and AV-aware switching features in a 1RU form factor that integrates cleanly into professional rack builds.

System Characteristics

• Dense 10G SFP+ connectivity supports larger optical media networks
• 25G SFP28 ports add uplink and aggregation bandwidth where needed
• No PoE design makes the switch role clearly transport and fiber focused
• Enhanced IGMP, AVB, and jumbo frame support align it with multicast-heavy and timing-sensitive workflows
• Multiple compatible PSU options support broader deployment and service planning

What’s In The Box

Please refer to the Specifications tab for the exact included items.
