NETGEAR 24x10G/Multi-Gig PoE+ (576W base, up to 720W) and 4xSFP28 25G (XSM4328CV) (TAA Compliant)

NETGEAR 24x10G/Multi-Gig PoE+ and 4xSFP28 25G Switch (XSM4328CV) (TAA Compliant) is built for AV and broadcast network environments where powered copper endpoints and faster uplinks both matter. Based on the source details, this switch provides 28 total ports, including 24 x 10G/Multi-Gig PoE+ ports and 4 x 25G SFP28 ports, making it a strong fit for edge deployments that need both endpoint power and upstream bandwidth.

Highlights

• 24 x 10G/Multi-Gig PoE+ ports for high-speed powered endpoint connectivity
• 4 x 25G SFP28 ports for uplinks and aggregation bandwidth
• Up to 720W PoE budget with 30W per port support
• Enhanced IGMP support, AVB included, and jumbo frames up to 12kb
• TAA compliant for procurement environments where that requirement matters

Quick Specs & Uses

• Width: 440 mm
• Depth: 400 mm
• Height: 43.2 mm
• Weight: 6.58 kg (14.51 lb)
• Primary port speed: 10 Gigabit / Multi-Gig
• Number of ports: 28 (24 x 10G/Multi-Gig PoE+, 4 x 25G SFP28)
• PoE ports / budget: 24 PoE+ (30W/port), 576W Base, up to 720W Budget
• IGMP support: Enhanced (NETGEAR IGMP Plus)
• Jumbo frame support: Yes, up to 12kb
• AVB support: Yes, included
• Acoustics: Quiet Mode 34.7dB @ 25°C
• Power consumption: With PoE 750.1W / 2557.84Btu/hr; Without PoE 119.4W / 374.92Btu/hr; Standby without any port connection 53.6W / 168.3Btu/hr
• PSU compatible models: APS350Wv1, APS600Wv2, APS920Wv1, APS2000Wv1

Why It Helps

In higher-density AV and broadcast systems, the edge switch often has to do more than simply connect devices. It has to power endpoints reliably, carry traffic cleanly, and still leave enough uplink capacity for the design to scale. The XSM4328CV fits that role well by combining Multi-Gig PoE+ access, 25G uplinks, and AV-aware switching features in a single 1RU platform.

System Characteristics

• High-speed Multi-Gig PoE+ access supports powered copper endpoint deployments
• 25G SFP28 uplinks add bandwidth for aggregation and backbone traffic
• Meaningful PoE budget makes the switch practical for larger powered device counts
• Enhanced IGMP, AVB, and jumbo frame support align it with multicast-heavy and timing-sensitive workflows
• Multiple compatible PSU options support broader deployment and long-term service planning

What’s In The Box

Please refer to the Specifications tab for the exact included items.
