NETGEAR MSM4320 16x 2.5G PoE++ (530W base, up to 1,130W) incl. 8x Neutrik etherCON and 4xSFP28 25G Managed Switch

NETGEAR MSM4320 16x 2.5G PoE++ (530W base, up to 1,130W) incl. 8x Neutrik etherCON and 4xSFP28 25G Managed Switch is built for AV and broadcast environments where powered endpoint density, ruggedized copper connectivity, and faster uplinks all need to work together in the same chassis. Based on the source details, this switch provides 20 total ports, including 16 x 2.5G PoE++ ports with 8 x Neutrik etherCON connections and 4 x 25G SFP28 uplinks, making it a strong fit for more demanding production and installed AV systems.

Highlights

• 16 x 2.5G PoE++ ports for powered AV endpoint connectivity
• 8 x Neutrik etherCON connections for more production-ready copper integration
• 4 x 25G SFP28 uplinks for upstream bandwidth and aggregation
• 2 internal 800W PSUs with PowerCON connectors
• Enhanced IGMP support, AVB included, and jumbo frames up to 12kb

Quick Specs & Uses

• Width: 440 mm
• Depth: 432 mm
• Height: 43.2 mm
• Weight: 7.85 kg (17.31 lb)
• Primary port speed: 2.5 Gigabit
• Number of ports: 20 (16 x 2.5G PoE++ incl. 8 x Neutrik etherCON, and 4 x 25G SFP28)
• IGMP support: Enhanced (NETGEAR IGMP Plus)
• Jumbo frame support: Yes, up to 12kb
• AVB support: Yes, included
• Acoustics: Quiet Mode 35.6 dB at 25°C
• Power consumption: With max PoE 1359.8W / 4,639.64 Btu/hr; Without PoE 109.6W / 373.96 Btu/hr; Standby without any port connection 50.6W / 170.60 Btu/hr
• PSU compatible models: Internal only
• Internal PSUs: 2 internal 800W PSUs with PowerCON connectors
• Compatible interface cards: APM414SD, APM414LD, APM414V, APM414C

Why It Helps

In real AV and broadcast systems, the switch often needs to do more than simply connect endpoints. It has to support powered devices, handle tougher connector requirements, and still leave enough uplink capacity so the network does not become the bottleneck. The MSM4320 fits that role well, combining 2.5G PoE++ access, etherCON integration, 25G uplinks, and AV-aware switching behavior in a single 1RU platform.

System Characteristics

• 2.5G PoE++ endpoint design supports powered AV devices in demanding environments
• Neutrik etherCON connectivity helps the switch fit better into production-oriented cabling workflows
• 25G SFP28 uplinks add upstream headroom for aggregation and backbone traffic
• Dual internal PSUs with PowerCON support more serious rack-level power design
• IGMP Plus, AVB, and jumbo frame support align it with multicast-heavy and timing-sensitive media workflows

What’s In The Box

Please refer to the Specifications tab for the exact included items.
