NETGEAR M4350-16V4C 16-Port 25G SFP28 Managed AV Network Switch

NETGEAR M4350-16V4C 16-Port 25G SFP28 Managed AV Network Switch is built for AV and broadcast network environments where bandwidth, uplink speed, and predictable traffic handling matter more than sheer port count. Based on the source details, this switch provides 20 total ports, including 16 x 25G SFP28 ports and 4 x 100G QSFP28 uplinks, making it a strong fit for high-speed aggregation, transport, and fiber-heavy media workflows.

Highlights

• 16 x 25G SFP28 ports for high-bandwidth endpoint or aggregation connectivity
• 4 x 100G QSFP28 uplinks for backbone and inter-switch capacity
• Enhanced IGMP support, AVB included, and jumbo frames up to 12kb
• No PoE budget, positioning the switch for fiber transport rather than powered edge access
• Quiet Mode acoustics rated at 33.4 dB at 25°C

Quick Specs & Uses

• Width: 440 mm
• Depth: 400 mm
• Height: 43.2 mm
• Weight: 7.15 kg (15.77 lb)
• Primary port speed: 25 Gigabit
• Number of ports: 20 (16 x 25G SFP28, 4 x 100G QSFP28)
• PoE ports / budget: N/A
• IGMP support: Enhanced (NETGEAR IGMP Plus)
• Jumbo frame support: Yes, up to 12kb
• AVB support: Yes, included
• Acoustics: Quiet Mode 33.4dB @ 25°C
• Power consumption: 143.4W / 450.28Btu/hr; standby without any port connection: 60.4W / 189.66Btu/hr
• PSU compatible models: APS600Wv3, APS1200Wv2, APS2000Wv2

Why It Helps

In higher-performance AV and broadcast systems, not every switch is there to power devices. Some are there to move large amounts of traffic cleanly and reliably. The M4350-16V4C fits that role well, combining 25G fiber connectivity, 100G uplinks, and AV-aware switching features in a 1RU form factor suited to professional rack environments.

System Characteristics

• 25G SFP28 connectivity supports higher-throughput AV and media network designs
• 100G QSFP28 uplinks provide strong backbone and aggregation capacity
• No PoE design makes the role of the switch more clearly transport and uplink focused
• Enhanced IGMP, AVB, and jumbo frame support align it with multicast-heavy and timing-sensitive workflows
• Multiple compatible PSU options support broader planning for deployment and service strategy

What’s In The Box

Please refer to the Specifications tab for the exact included items.
