NETGEAR AV Line M4350-24F4X 24-Port Gigabit SFP Managed Switch

NETGEAR AV Line M4350-24F4X 24-Port Gigabit SFP Managed Switch is built for AV and broadcast network environments where fiber connectivity matters more than PoE. Based on the source details, this switch provides 29 total connections supporting up to 10 GbE, making it a strong fit for optical media and infrastructure networks that need cleaner transport-focused switching.

Highlights

• 24 x SFP Gigabit Ethernet ports for dense fiber connectivity
• 4 x RJ45/SFP combo 10 GbE ports for flexible uplinks and handoff points
• Layer 3 support, IGMP Snooping, and jumbo frames up to 12,000 bytes
• Stackable design for larger switch deployments
• 200 Gb/s switching bandwidth with a 30 dB fan noise level

Quick Specs & Uses

• Networking I/O: 29 total connections supporting up to 10 GbE
• Ports: 24 x SFP Gigabit Ethernet, 4 x RJ45/SFP combo 10 GbE, 1 x RJ45 Gigabit Ethernet
• Other I/O: 1 x USB-C, 2 x USB-A
• Stackable: Yes
• Layer services supported: Layer 3
• Supported protocols: Auto-MDI/MDI-X, DHCP Server, IGMP Snooping, RIPv6
• Jumbo frame support: 12,000 bytes
• MAC address table size: 16K
• Security features: DHCP Snooping
• Forwarding rate: 148.8 Mpps
• Switching bandwidth: 200 Gb/s
• Packet buffer: 32 Mb
• CPU: Quad-core up to 1.8 GHz Cortex A57
• Memory: 4 GB DDR4
• Power draw: 115.5 W max
• Power supply type: Internal
• Cooling system: Fan, 30 dB noise level
• Rack mountable: Yes, 1RU
• Dimensions: 17.3 x 15.7 x 1.7 in / 440 x 400 x 43.2 mm
• Weight: 16.2 lb / 7.38 kg

Why It Helps

In real AV systems, not every switch is there to power endpoints. Some are there to carry traffic cleanly across a fiber-heavy network and give the design a bit of higher-speed uplink flexibility where it counts. The M4350-24F4X fits that role well, combining dense SFP connectivity, 10 GbE combo uplinks, and AV-aware management features in a single 1RU platform.

System Characteristics

• Fiber-first port layout supports optical AV network design
• 10 GbE combo ports add flexibility for uplinks and mixed media handoff
• Layer 3, IGMP Snooping, and jumbo frame support align with multicast-aware AV workflows
• Stackable 1RU format helps the switch scale in larger rack builds
• Low 30 dB cooling figure makes it easier to place in shared technical spaces

What’s In The Box

Please refer to the Specifications tab for the exact included items.
