NETGEAR AV Line M4250 GSM4230PX 24-Port Gigabit PoE+ Compliant Managed Network Switch with SFP+ (480W)

NETGEAR AV Line M4250 GSM4230PX 24-Port Gigabit PoE+ Compliant Managed Network Switch with SFP+ (480W) is built for AV and broadcast network environments where powered Gigabit edge ports and proper uplinks both matter. Based on the source details, this switch provides 30 total ports, including 24 x 1G PoE+ ports, 2 x 1G ports, and 4 x SFP+ uplinks, making it a strong fit for AV edge deployments that need both endpoint power and cleaner upstream bandwidth.

Highlights

• 24 x 1G PoE+ ports for powered endpoint connectivity
• 2 x 1G copper ports for extra network flexibility
• 4 x SFP+ uplinks for faster upstream links and aggregation
• 480W PoE budget for practical powered device support
• Domotz support for third-party monitoring

Quick Specs & Uses

• Primary port speed: 1 Gigabit
• Number of ports: 30 (24x 1G PoE+, 2x 1G, 4x SFP+)
• PoE ports / budget: 24 PoE+ (30W/port), 480W Budget
• IGMP support: Enhanced (NETGEAR IGMP Plus)
• Jumbo frame support: Yes, up to 12kb
• AVB support: Yes, electronic license required, activation key sent via email (AVB4230PX-10000S)
• Acoustics: Fanless or 42 dB @ 25°C
• Power consumption: With PoE 614W / 2096.2 Btu/hr; Without PoE 46.8W / 159.78Btu/hr; Standby without any port connection 33.9W / 115.73Btu/hr
• Third-party support: Domotz

Why It Helps

In real AV edge deployments, a switch often has to do more than simply provide port count. It has to power endpoints, support multicast traffic cleanly, and still leave enough uplink capacity for the design to scale. The GSM4230PX fits that role well by combining Gigabit PoE+, SFP+ uplinks, and AV-aware switching features in one managed platform.

System Characteristics

• 24-port Gigabit PoE+ access supports powered AV edge devices
• Extra 1G copper ports add flexibility for supporting devices or network connections
• SFP+ uplinks add cleaner upstream bandwidth where needed
• Enhanced IGMP and optional AVB support align it with multicast-heavy and timing-sensitive workflows
• Domotz support adds value for third-party monitoring and operational visibility

What’s In The Box

Please refer to the Specifications tab for the exact included items.
