NETGEAR GS752TXUPv3 48-Port Gigabit PoE++ Managed Network Switch

NETGEAR GS752TXUPv3 48-Port Gigabit PoE++ Managed Network Switch is built for dense powered edge deployments where a large number of copper-connected devices, mixed PoE requirements, and proper uplinks all need to work together in the same chassis. Based on the source details, this switch combines 48 Gigabit Ethernet ports with 4 x 10G SFP+ uplinks, making it a strong fit for larger access-layer environments that still need clean upstream bandwidth.

Highlights

• 48 x 10/100/1000 Mbps ports for dense copper access connectivity
• 4 x 10G SFP+ uplinks for fiber handoff and inter-switch links
• 32 PoE+ ports and 16 PoE++ ports for mixed powered device support
• 640W total PoE budget for larger powered endpoint deployments
• Supports 512 VLANs with VLAN routing and dynamic VLAN assignment

Quick Specs & Uses

• Width: 440 mm
• Depth: 310 mm
• Height: 43 mm
• Weight: 4.79 kg (10.56 lb)
• Model description: 48-Port Gigabit Ethernet Ultra60 PoE++ Smart Switch with 4 10G SFP+ Ports
• 10/100/1000 Mbps ports: 48
• 10G SFP+ ports: 4
• Number of PoE+ ports: 32
• Number of PoE++ ports: 16
• Total PoE power budget: 640W
• Max MAC entries: 16K
• Buffer size: 1.5MB
• VLANs supported: 512
• VLAN routing: Yes
• Dynamic VLAN assignment: Yes
• MLD Snooping: Yes
• Static route: Yes
• Host ARP table: 512
• EEE: Yes
• DoS prevention: Yes
• Power supply: Internal
• Max consumption without PoE: 67W
• Fans: 2
• Acoustic noise level: 37.3 dBA at 25°C
• Operating temperature: 0° to 50°C
• MTBF: 191,643 hours (21.9 years)

Why It Helps

In real deployments, the access layer often has to do more than just connect devices. It has to power them, keep traffic organized, and still hand everything off cleanly upstream. The GS752TXUPv3 fits that role well, combining dense Gigabit access, mixed PoE+ and PoE++ support, and 10G SFP+ uplinks in a rack-friendly managed platform.

System Characteristics

• Dense Gigabit edge design supports larger powered device deployments
• 4 x 10G SFP+ uplinks provide clean upstream handoff and inter-switch flexibility
• Mixed PoE+ and PoE++ support helps match different powered endpoint requirements
• VLAN routing, MLD Snooping, and static routes support more controlled deployment design
• Internal PSU and managed feature set help the switch fit better into real technical environments

What’s In The Box

Please refer to the Specifications tab for the exact included items.
