NETGEAR GS752TXv3 48-Port Gigabit Managed Network Switch

NETGEAR GS752TXv3 48-Port Gigabit Managed Network Switch is built for managed access-layer environments where endpoint density matters more than PoE or fiber-heavy design. Based on the source details, this switch provides 52 total connections supporting up to 10 GbE, including 48 x RJ45 Gigabit Ethernet ports and 4 x SFP+ 10 GbE uplinks, making it a strong fit for larger copper-based network deployments that still need cleaner upstream bandwidth.

Highlights

• 48 x RJ45 Gigabit Ethernet ports for dense copper access connectivity
• 4 x SFP+ 10 GbE uplinks for aggregation and inter-switch links
• Layer 2, Layer 3, and Layer 4 services for more structured network control
• IGMP Snooping, RADIUS, and DHCP Snooping for managed deployment support
• 176 Gb/s switching bandwidth in a rack-mount 1RU form factor

Quick Specs & Uses

• Networking I/O: 52 total connections supporting up to 10 GbE
• Ports: 48 x RJ45 Gigabit Ethernet, 4 x SFP+ 10 GbE
• Stackable: No
• Layer services supported: Layer 2, Layer 3, Layer 4
• Supported protocols: Auto-MDI/MDI-X, DHCP Server, IGMP Snooping, IPv4, IPv6, Port Mirroring, RADIUS
• Queueing: Weighted Round Robin (WRR)
• Jumbo frame support: 10,000 bytes
• MAC address table size: 16K
• Security features: DHCP Snooping, RADIUS Authentication
• Forwarding rate: 130.94 Mpps
• Switching bandwidth: 176 Gb/s
• Packet buffer: 1.5 MB
• CPU: Single-core up to 800 MHz
• Power supply type: Internal
• Cooling system: Fan, 50.5 dB noise level
• Operating conditions: 32 to 122°F / 0 to 50°C up to 90% humidity
• Storage conditions: -4 to 158°F / -20 to 70°C up to 95% humidity
• Rack mountable: Yes
• Dimensions: 17.3 x 10.1 x 1.7 in / 440 x 257 x 43 mm
• Weight: 7.8 lb / 3.53 kg
• Certifications: BSMI, CE, FCC, ICES, KC, RCM, UKCA, VCCI

Why It Helps

In real managed networks, some switches are there to power devices and others are there to provide a lot of stable copper access while keeping the uplink side clean. The GS752TXv3 fits the second role well, combining dense Gigabit access, 10G SFP+ uplinks, and layered management features in a rack-friendly platform built for structured deployments.

System Characteristics

• Dense Gigabit access layout supports larger wired endpoint environments
• 4 x 10G SFP+ uplinks provide cleaner upstream bandwidth and switching flexibility
• Layer 2 to Layer 4 support helps the switch fit more structured network designs
• IGMP Snooping, DHCP Snooping, and RADIUS support managed operational control
• Rack-mount design with internal PSU supports cleaner infrastructure integration

What’s In The Box

Please refer to the Specifications tab for the exact included items.
