NETGEAR WAX620PA AX3600 Wireless Dual-Band 2.5 Gigabit Access Point with Power Adapter

NETGEAR WAX620PA AX3600 Wireless Dual-Band 2.5 Gigabit Access Point with Power Adapter is built for business-class indoor wireless deployments that need stronger throughput, flexible deployment modes, and structured security without unnecessary complexity. Based on the source details, this access point delivers 3600 Mb/s total throughput, split across 5 GHz at 2400 Mb/s and 2.4 GHz at 1200 Mb/s, making it a practical fit for managed wireless environments where performance and flexibility both matter.

Highlights

• AX3600 dual-band wireless performance for business-focused WiFi deployments
• Supports up to 256 clients with up to 8 SSIDs
• Access Point, Bridge, Mesh, and Repeater modes for more flexible deployment design
• WPA, WPA2, WPA2-Enterprise, WPA3, and WPA3-Enterprise security support
• Wall and ceiling mount options with local power adapter support

Quick Specs & Uses

• Throughput: 3600 Mb/s total
• 5 GHz throughput: 2400 Mb/s
• 2.4 GHz throughput: 1200 Mb/s
• Number of antennas: 1
• Antenna gain: 3.1 to 4.3 dBi
• Supported protocols: MAC Filtering, SSID
• Antenna placement: Internal
• Bluetooth: No
• Guest network support: Yes
• Wireless security: WPA, WPA2, WPA2-Enterprise, WPA3, WPA3-Enterprise
• Lock slot: No
• Operation modes: Access Point, Bridge, Mesh, Repeater
• Supported clients: 256
• Max SSIDs supported: 8
• Mobile app compatible: Yes, Android and iOS
• Supported IEEE standards: 802.11a, 802.11ac, 802.11ax, 802.11b, 802.11g, 802.11n, 802.3af, 802.3at
• Input power: 12 VDC at 3.5 A
• Power consumption: 25.5 W
• Environmental resistance: No
• Operating conditions: 32 to 104°F / 0 to 40°C up to 90% humidity
• Storage conditions: -4 to 158°F / -20 to 70°C up to 95% humidity
• Mount options: Wall, Ceiling
• Dimensions: 8.1 x 8.1 x 1.4 in / 205.7 x 205.7 x 34.3 mm
• Weight: 1.7 lb / 783 g

Why It Helps

In real wireless deployments, the access point needs to do more than just provide coverage. It needs to support client density, fit into the intended mounting plan, and offer security and segmentation options that make sense in an actual business network. The WAX620PA fits that role well by combining AX3600 dual-band performance, multiple deployment modes, and business-grade SSID and security support in a compact indoor platform.

System Characteristics

• Dual-band AX3600 design supports stronger business wireless performance
• Support for 256 clients and 8 SSIDs helps with denser and more segmented deployments
• AP, bridge, mesh, and repeater modes give installers more flexibility in the field
• WPA3 and WPA3-Enterprise support support more secure managed wireless access
• Wall and ceiling installation with local power adapter supports cleaner indoor deployment planning

What’s In The Box

Please refer to the Specifications tab for the exact included items.
