NETGEAR AV Line M4250-40G8XF-PoE+ (GSM4248PX) 40x1G PoE+ 960W and 8xSFP+ Managed Switch (TAA Compliant)

NETGEAR AV Line M4250-40G8XF-PoE+ (GSM4248PX) 40x1G PoE+ 960W and 8xSFP+ Managed Switch (TAA Compliant) is built for AV and broadcast network environments where high endpoint density, powered device support, and clean uplinks all need to coexist in the same chassis. Based on the source details, this switch provides 48 total ports, including 40 x 1G PoE+ ports and 8 x SFP+ uplinks, making it a strong fit for larger AV edge deployments that still need proper upstream bandwidth.

Highlights

• 40 x 1G PoE+ ports for high-density powered endpoint connectivity
• 8 x SFP+ uplinks for faster upstream links and aggregation
• 960W PoE budget for larger powered device deployments
• Enhanced IGMP support and jumbo frames up to 12kb
• TAA compliant for procurement environments where that requirement matters

Quick Specs & Uses

• Primary port speed: 1 Gigabit
• Number of ports: 48 (40x 1G PoE+, 8x SFP+)
• PoE ports / budget: 40 PoE+ (30W/port), 960W Budget
• IGMP support: Enhanced (NETGEAR IGMP Plus)
• Jumbo frame support: Yes, up to 12kb
• AVB support: Yes, electronic license required, activation key sent via email (AVB4248PX-10000S)
• Acoustics: Fanless or 59 dB @ 25°C
• Power consumption: With PoE 1197W / 4086.56 Btu/hr; Without PoE 89.2W / 304.53 Btu/hr; Standby without any port connection 74.5W / 254.34 Btu/hr
• Third-party support: Domotz

Why It Helps

In larger AV and broadcast edge deployments, the switch often has to do more than simply provide ports. It has to power endpoints reliably, carry traffic cleanly, and still leave enough uplink capacity for the design to scale. The M4250-40G8XF-PoE+ fits that role well by combining high-density Gigabit PoE+, SFP+ uplinks, and AV-aware switching features in a single managed platform.

System Characteristics

• High-density Gigabit PoE+ access supports larger powered endpoint counts
• SFP+ uplinks add cleaner upstream bandwidth where needed
• Large PoE budget makes the switch more practical for real endpoint loads
• Enhanced IGMP and optional AVB support align it with multicast-heavy and timing-sensitive workflows
• Domotz support adds value for third-party monitoring and operational visibility

What’s In The Box

Please refer to the Specifications tab for the exact included items.
