Matrox Vion NX Compact IP Video Gateway With IP Inputs

Matrox Vion NX Compact IP Video Gateway With IP Inputs is built for broadcast and professional AV systems that need to move video between baseband and IP workflows without adding several separate conversion boxes. It handles IP signal and protocol conversion, multichannel encoding and decoding, and cross-conversion from one compact appliance.

The Vion NX supports multichannel 4K operation with video processing through H.264, H.265, JPEG XS, and NDI. Two 12G-SDI inputs, two Mini-HDMI inputs, dual HDMI outputs, and both Gigabit and 2.5 GbE network connections give engineers several ways to bring sources into the unit and route processed video back into the system.

Highlights

• IP signal and protocol conversion – bridges different network video formats and transport requirements
• Multichannel 4K processing – handles several high-resolution video streams from one compact gateway
• Low-latency encoding – designed for professional workflows where delay needs to stay controlled
• Baseband-to-IP conversion – accepts HDMI and 12G-SDI sources for encoding into network video
• H.264, H.265, JPEG XS, and NDI support – provides several codec choices for different production environments
• Up to 8 simultaneous streams – supports multi-source gateway and conversion applications

Quick Specs & Uses

• Product type: Compact IP video gateway
• Primary functions: Encoding, decoding, transcoding, protocol conversion, and IP video cross-conversion
• Video inputs: 2 x Mini-HDMI; 2 x Micro BNC (12G-SDI)
• Video outputs: 2 x HDMI
• Embedded audio: HDMI / SDI, up to 8 channels
• Analog audio input: 1 x 5-pin stereo block; 1 x 1/8" / 3.5 mm TRS
• Analog audio output: 1 x 1/8" / 3.5 mm TRS
• Network I/O: 1 x RJ45 10/100/1000 Ethernet; 1 x RJ45 2.5 GbE
• USB: 5 x USB-A; 1 x USB-C
• IP video codecs: H.264, H.265, JPEG XS, NDI
• Maximum IP video resolution: 4096 × 2160 at 60 fps
• IP video range: 4096 × 2160 to 1920 × 1080 at 60 fps
• Transport protocols: NDI / HX3, RTP, RTSP, SRT, TS-MPEG
• Simultaneous streams: Up to 8
• Internal recording: No
• Reclocking: No
• Media / memory card slot: No
• Wireless: No
• Cellular support: No
• Power input: 1 x barrel, 19 VDC at 4.5 A
• Power supply: 120 to 240 VAC, 90 W
• Operating temperature: 0 to 35°C (32 to 95°F)
• Certifications: CE, FCC, ICES-003, KC, RCM, REACH, RoHS
• Dimensions: 190 × 148 × 30 mm (7.5 × 5.8 × 1.2 in)
• Weight: 1 kg (2.2 lb)

Why It Helps

A gateway becomes useful when the sources arriving at a facility do not all speak the same language. One feed may come in over SDI, another over HDMI, and another over an IP protocol. The Vion NX gives engineers one place to encode, decode, transcode, or cross-convert those signals rather than building a chain of individual converters.

The mix of 12G-SDI, HDMI, Gigabit Ethernet, and 2.5 GbE also makes the appliance easier to place between established baseband equipment and newer IP infrastructure. That is particularly useful during system upgrades, where both types of signal may need to remain active at the same time.

With support for as many as eight simultaneous streams, the Vion NX can handle more than a simple one-input, one-output conversion. It is better suited to multi-source environments where several feeds need to be processed together while keeping the hardware footprint relatively small.

System Characteristics

• Baseband and IP integration connects HDMI and 12G-SDI equipment with network-based video workflows
• Multiformat codec processing supports H.264, H.265, JPEG XS, and NDI from the same gateway
• Eight-stream capability supports higher-density production and distribution systems
• Dual-speed Ethernet connectivity provides both standard Gigabit and 2.5 GbE network interfaces
• Multichannel 4K support keeps the appliance useful in UHD production environments
• Compact standalone design reduces the amount of separate conversion hardware needed in the signal path

What's In The Box

• 1 x Matrox Vion NX Compact IP Video Gateway With IP Inputs
• 1 x Power Supply
• 1 x Power Cord
• 2 x BNC Cables (1')
• 1 x Mounting Plate with Screws
