Matrox Two (2) NRG Redundant Power Supply Unit Preinstalled On A Rack Tray

Matrox Two (2) NRG Redundant Power Supply Unit Preinstalled On A Rack Tray puts two NRG redundant power supply units into a single 1 RU rack-mounted assembly. Each half-rack RPSU contains two hot-swappable 300 W power modules, giving broadcast and AV racks a cleaner way to distribute redundant power without installing separate supplies around each device.

Each RPSU can simultaneously power up to five Matrox devices, so the two-unit tray can cover as many as ten devices. Ten DIN 4-pin outputs handle the downstream power connections, while IP connectivity gives engineers a way to monitor and control the power system from the network.

Highlights

• 2 preinstalled NRG RPSUs – supplied together on a single 1 RU rack tray
• Power for up to 10 Matrox devices – each redundant supply can feed as many as five devices
• 2 hot-swappable modules per RPSU – each unit uses two redundant 300 W power modules
• 10 DIN 4-pin outputs – provides multiple downstream connections for Matrox equipment
• IP monitoring and control – adds network access for checking and managing the power system
• 1 RU rack installation – keeps both redundant supplies together in a compact rack-mounted package

Quick Specs & Uses

• Product type: Dual redundant power supply rack assembly
• Power source: AC input
• AC power inputs: 4 x IEC C13
• Power outputs: 10 x DIN 4-pin
• AC input power: 100 to 240 VAC, 50 / 60 Hz
• Hot-swappable modules: 2 per RPSU
• Power module rating: 300 W each
• Device capacity: Up to 5 Matrox devices per RPSU; up to 10 devices across the two-unit tray
• Monitoring and control: IP connectivity
• Mounting: 4 x rack tray mounting holes
• Color: Black
• NRG unit dimensions: 244 × 216 × 43 mm (9.6 × 8.5 × 1.7 in)
• Rack tray dimensions: 483 × 290.8 × 44.5 mm (19 × 11.45 × 1.75 in)
• Weight: 4.8 kg (10.6 lb)
• Operating conditions: 0 to 50°C (32 to 122°F)
• Storage conditions: -18 to 80°C (0 to 176°F)

Why It Helps

Once several Matrox devices are installed in the same rack, separate power supplies can quickly turn into extra cabling, occupied outlets, and more hardware to keep track of. This dual-RPSU tray brings those power connections into one 1 RU assembly and can serve as many as ten devices.

The redundant design also matters in systems that are expected to stay online. Each RPSU uses two hot-swappable 300 W power modules, so the power section is built around replaceable redundant modules rather than a single fixed supply.

Network connectivity gives engineers another useful layer of visibility. Instead of treating the power system as a passive rack component, the NRG units can be monitored and controlled over IP while the DIN 4-pin outputs distribute power to the connected Matrox equipment.

System Characteristics

• Dual-RPSU architecture places two redundant power supplies together on one 1 RU rack tray
• Ten-device power capacity supports larger Matrox installations from a centralized rack position
• Hot-swappable 300 W modules make individual power-module replacement possible within each RPSU
• DIN 4-pin distribution provides ten dedicated outputs for connected devices
• IP-based monitoring gives engineers network access to power-system status and control
• Rack-ready installation keeps power hardware organized for broadcast and professional AV environments

What's In The Box

• 2 x Matrox NRG Redundant Power Supply Units Preinstalled on Rack Tray
• 1 x Rack Tray
• 2 x Double-Ended DIN 4 Cables
• 4 x Tray Mounting Screws
