Matrox Mura DVW IP-Based Distributed Video Wall Appliance

Matrox Mura DVW IP-Based Distributed Video Wall Appliance is designed for distributed video wall installations where synchronized 4K displays need to be driven from IP sources. It decodes H.264 and H.265 video streams and sends them to four local HDMI outputs, giving system designers a practical building block for larger display walls.

A single appliance can feed four displays at up to 4K60, while multiple units can be combined to create synchronized surfaces with as many as 64 4K displays. The hardware also includes dual RJ45 network connections, USB-A and USB-C ports, analog audio connections, and mounting options for rack or VESA-based installations.

Highlights

• Distributed 4K video wall processing – built for synchronized IP-based multi-display installations
• Four HDMI outputs – drives up to four local displays from one appliance
• Up to 4K60 output – supports HDMI video up to 4096 × 2160 at 60 fps
• H.264 and H.265 decoding – handles common compressed IP video formats
• Scalable display architecture – supports systems with up to 64 synchronized 4K displays
• USB and network connectivity – provides dual RJ45, USB-A, and USB-C interfaces for integration and control

Quick Specs & Uses

• Product type: IP-based distributed video wall appliance
• Video decoding: H.264, H.265
• Video outputs: 4 x HDMI
• Maximum HDMI output: 4096 × 2160 at 60 fps
• RJ45 input format: Up to 7680 × 4320 at 60 fps
• Maximum synchronized display system: Up to 64 4K displays
• Network I/O: 2 x RJ45
• USB: 5 x USB-A; 1 x USB-C
• Microphone input: 1 x 1/8" / 3.5 mm TRS
• Analog audio output: 1 x 1/8" / 3.5 mm TRS
• Embedded audio: No
• HDR support: No
• HDCP support: No
• EDID support: No
• Audio decoding: No
• Power input: 1 x barrel, 19 VDC at 4.7 A
• Power consumption: 45 W
• Rack form factor: 1 RU
• Mounting: VESA mount bracket included
• Operating conditions: 0 to 40°C (32 to 104°F), 10 to 90% humidity
• Storage conditions: -20 to 70°C (-4 to 158°F), 20 to 80% humidity
• Certifications: REACH, RoHS, TAA, WEEE
• Dimensions: 190 × 148 × 30 mm (7.5 × 5.8 × 1.2 in)

Why It Helps

A large video wall can become difficult to manage when every display depends on its own source or processor. The Mura DVW takes a distributed approach instead, letting one appliance handle four HDMI outputs while several units work together as part of the same synchronized wall.

That makes the appliance useful for control rooms, monitoring walls, dashboards, and other environments where several 4K displays need to stay aligned. The ability to scale up to 64 synchronized screens gives engineers room to build larger installations without changing the basic hardware approach.

The compact chassis also keeps deployment flexible. It can sit in a rack or mount using the included VESA bracket, while its network and USB connections give integrators straightforward access for system connectivity and peripheral support.

System Characteristics

• Distributed video wall architecture allows multiple appliances to work together across a synchronized display surface
• Four-output local processing gives each appliance direct control of several HDMI displays
• 4K60 video support fits high-resolution monitoring and visualization environments
• H.264 / H.265 decoding allows compressed IP video streams to be used as wall content
• Scalable synchronization supports deployments ranging from a few displays to larger 64-screen systems
• Compact 1 RU design makes the appliance easier to place in racks or behind displays using VESA mounting

What's In The Box

• 1 x Matrox Mura DVW IP-Based 4K Video Wall Appliance
• 1 x VESA Mount Bracket
• 1 x Power Cord (US/Canada)
