Matrox Extio N3408 IP KVM Transmitter Card

Matrox Extio N3408 IP KVM Transmitter Card installs directly into a workstation to bring that system into an Extio 3 IP KVM environment. It carries display, USB, audio, and control traffic over standard Gigabit Ethernet, letting the computer stay in a secure machine room while the operator works from a remote desk or control position.

The card is built for high-resolution and multi-display workflows, with three Mini DisplayPort 1.1 inputs and one Mini DisplayPort 1.2 input. Extio N3408 supports 4K60 4:4:4 applications as well as multi-screen desktops, while the network side can run over copper or optional fiber depending on the distance and installation.

Highlights

• PCIe IP KVM transmitter – connects a host workstation directly to the Matrox Extio 3 environment
• 4K60 4:4:4 support – built for detailed high-resolution desktop and professional visualization workflows
• Multi-display operation – supports several display signals from one workstation
• Gigabit Ethernet transport – carries KVM traffic over standard 1 GbE network infrastructure
• Copper or fiber connectivity – lets engineers choose the physical transport around distance and installation requirements
• Flexible KVM routing – supports unicast, multicast, and multi-unicast operation

Quick Specs & Uses

• Product type: PCI Express IP KVM transmitter card
• System family: Matrox Extio 3 / Extio N3408
• Bus interface: PCI Express x8 electrical, x16 mechanical
• Video inputs: 3 x Mini DisplayPort 1.1; 1 x Mini DisplayPort 1.2
• USB: 1 x Mini USB 2.0 Type-B
• Network connection: 1 x RJ45 copper transceiver, replaceable with optional fiber-optic transceiver
• Video capability: Up to 4K60 4:4:4 applications
• Proxy stream resolution: 1 x 1920 × 1080 at 60 Hz, YUV 4:2:0 (not yet enabled in the provided source)
• USB support: Keyboard, mouse, touchscreens, USB 2.0 mass storage, industrial keyboards, smart card / CAC readers, USB speakers, sound bars, and other USB HID devices
• Audio: Digital audio embedded in DisplayPort
• Network standard: 1000BASE-T Ethernet
• Network mode: Auto-detect, half/full duplex
• Routing: Unicast, multicast, multi-unicast
• IP addressing: IPv4; DHCP or static IP
• Maximum copper distance: 100 m (328 ft) using Cat5e or Cat6
• Maximum multimode fiber distance: Up to 550 m (1804 ft), depending on fiber type
• Maximum single-mode fiber distance: Up to 10 km (6.20 mi)
• Maximum distance over IP: LAN, private WAN, or internet
• Card format: Full-height, 3/4-length
• Dimensions: 229.1 × 111.2 mm (9.020 × 4.376 in)
• Status indication: 1 x LED indicator for status and power
• Supported management software: Matrox Extio Central Manager
• Software platform support: Microsoft Windows 10 64-bit, Windows 7 32-bit / 64-bit, Windows Server 2016, Windows Server 2012 R2, Windows Server 2008 R2

Why It Helps

In broadcast, post-production, control-room, and visualization environments, the workstation often belongs in the equipment room rather than under the operator's desk. The N3408 transmitter card lets that computer stay centralized while its displays, USB peripherals, audio, and control are delivered to the working position over the IP network.

The card also gives engineers room to build larger desktops. High-resolution 4K60 operation and multi-display support make it suitable for workstations that need several screens for monitoring, graphics, editing, control, or other data-heavy applications.

Distance does not have to dictate where the workstation sits. Copper links can reach 100 meters, while optional fiber can extend the connection considerably farther. Over IP, Extio systems can also work across a LAN, private WAN, or internet connection when the network is suitable for the application.

System Characteristics

• Remote workstation access keeps computers centralized while operator positions stay clean and quiet
• 4K60 and multi-display support suits high-resolution broadcast, control-room, and visualization desktops
• Standard 1 GbE transport lets the KVM system use conventional network infrastructure
• Copper and optional fiber support gives integrators flexibility around short and long cable runs
• Scalable IP routing supports point-to-point and larger networked KVM architectures
• Extio Central Manager support provides centralized management for networked Extio devices

What's In The Box

• 1 x Matrox Extio N3408 IP KVM Transmitter Card
