Product Highlights
- 4K60 NDI IP video decoding
- NDI HX2 HX3 SRT support
- Picture-in-picture and quad-view decoding
- HDMI 2.0 HDR PoE Plus
Magewell Pro Convert IP to HDMI 4K60 NDI SRT HDR Decoder PoE Plus
- SKU:
- MAG-64410
- MPN:
- 64410
Ships in 1-3 Business Day
Free Expedited Shipping
Secure payment
Manufacturer Warranty
Authorized Dealer
Product Inquiry Form
Description
Product Overview
Magewell Pro Convert IP to HDMI 4K is a standalone IP video decoder for converting NDI, SRT, H.264, H.265, and other network video streams to HDMI 2.0. It supports single-view decoding up to 4096 × 2160p60, Picture-in-Picture, four-source Quad View, HDR PQ and HLG, Gigabit Ethernet, PoE+, and centralized remote management for broadcast, live production, monitoring, and AV-over-IP workflows.
4K60 IP Video Decoding
Single-view decoding supports one H.264, H.265, SpeedHQ, or MPEG2 stream at resolutions up to 4096 × 2160p60. The decoder converts network video into a baseband HDMI signal for confidence monitoring, presentation, control rooms, and professional display systems.
NDI High Bandwidth HX2 HX3 Decoder
Decode NDI High Bandwidth, NDI HX2, and NDI HX3 sources from an Ethernet network. NDI 6.3 support helps integrate the unit into modern IP production systems, remote studios, presentation spaces, and distributed video infrastructures.
SRT and Multi-Protocol IP Decoder
Beyond NDI, the decoder supports MPEG-TS over RTP, UDP, SRT, and RIST as well as RTMP, RTSP, HLS, HTTP, and ZIXI. H.264 and H.265 compatibility makes it useful for contribution feeds, remote production, streaming infrastructure, and IP video monitoring.
Two-Source Picture-in-Picture Decoding
Picture-in-Picture mode decodes two supported streams at resolutions up to 1920 × 1080p60. Supported formats include H.264, H.265, SpeedHQ, and MPEG2, providing a compact way to monitor a primary source alongside a secondary network feed.
Four-Source Quad View Decoder
Quad View mode combines up to four H.264 or H.265 IP streams into a single HDMI output. Supported sources can reach up to 1920 × 1080p60, making the decoder practical for multiview monitoring in studios, control rooms, production spaces, and AV systems.
HDR HDMI 2.0 and PoE+
HDMI 2.0 output supports resolutions up to 4096 × 2160 at 60 fps, BT.601, BT.709, and BT.2020 color spaces, plus HDR PQ and HLG. Gigabit Ethernet with IEEE 802.3at PoE+ can carry network connectivity and power through a single Ethernet connection.
Single View 4K60
Decodes one supported IP source at up to 4096 × 2160p60 for full-screen HDMI monitoring and presentation.
Picture-in-Picture
Displays two supported network streams with decoding resolutions up to 1920 × 1080p60.
Quad View
Combines up to four H.264 or H.265 network sources into a single multiview HDMI output.
HDR Output
Supports PQ and HLG HDR output alongside BT.601, BT.709, and BT.2020 color spaces.
Web UI
Configure decoding, output, audio, network, security, and system parameters from a supported desktop or mobile web browser.
Keyboard and Mouse
A USB Type-A interface accepts an external keyboard and mouse for local configuration and settings changes.
Centralized Management
Register the decoder with Magewell Control Hub or Zixi ZEN Master for remote centralized device management.
HTTP API Integration
HTTP APIs allow third-party control systems and custom applications to integrate with decoder functions.
Broadcast Monitoring
Convert network contribution or production feeds into HDMI for control-room confidence monitors and professional displays.
Live Production
Decode NDI and other IP sources for production monitoring, presentation, preview, and distributed video systems.
AV over IP
Bridge network video into HDMI-based projectors, displays, switchers, and presentation equipment.
Remote Production
Decode SRT, RIST, ZIXI, and other network feeds for remote contribution and distributed production environments.
| Specification | Detail |
|---|---|
| Product | Pro Convert IP to HDMI 4K |
| SKU | 644100000 |
| Part Number | 64410 |
| Product Type | IP Video Decoder |
| Single View Channels | 1 |
| Single View Resolution | Up to 4096 × 2160p60 |
| Single View Formats | H.264, H.265, SpeedHQ, MPEG2 |
| Picture-in-Picture Channels | 2 |
| Picture-in-Picture Resolution | Up to 1920 × 1080p60 |
| Picture-in-Picture Formats | H.264, H.265, SpeedHQ, MPEG2 |
| Quad View Channels | 4 |
| Quad View Resolution | Up to 1920 × 1080p60 |
| Quad View Formats | H.264, H.265 |
| NDI Support | NDI High Bandwidth, NDI HX2, NDI HX3 |
| NDI Version Support | NDI 6.3 |
| IP Protocols | NDI High Bandwidth, NDI HX2, NDI HX3, MPEG-TS over RTP, UDP, SRT and RIST, RTMP, RTSP, HLS, HTTP, and ZIXI |
| Audio Decode Formats | AAC, MP3, AC3, Opus, G.711 |
| HDMI Interface | HDMI 2.0 |
| Maximum HDMI Output | 4096 × 2160 at 60 fps |
| Color Space | BT.601, BT.709, BT.2020 |
| HDR | PQ and HLG |
| Audio Output | 48/96 kHz, up to 8 channels |
| Analog Audio Output | 1 × 3.5 mm line output |
| Ethernet | 10/100/1000 Mbps Gigabit Ethernet |
| PoE | IEEE 802.3at PoE+ |
| USB Type-C | 12V 20W power input and USB NET |
| USB Type-A | External keyboard and mouse support |
| Remote Management | Web UI, Magewell Control Hub, Zixi ZEN Master |
| Browser Support | Edge, Firefox, Chrome, Safari, Opera |
| API | HTTP APIs |
| Output Preview | Supported through Web UI |
| PTZ Control | Supported |
| Maximum Power Consumption | Approximately 12.12W |
| Dimensions | 4.72 × 3.12 × 0.96 in / 120 × 79.3 × 24.5 mm |
| Operating Temperature | 0 to 40°C |
| Storage Temperature | -20 to 70°C |
| Relative Humidity | 5% to 90% non-condensing |
| In the Box | Pro Convert IP to HDMI 4K × 1 · Universal power adapter × 1 · USB Type-C to Type-C cable × 1 · USB Type-C to Type-A cable × 1 · Fishtail bracket × 1 · Bracket fastener × 1 · M4 × 12 black screws × 2 · M4 black nuts × 2 |
What does Magewell Pro Convert IP to HDMI 4K do?
It decodes supported network video streams and converts them to an HDMI 2.0 signal. Typical applications include NDI monitoring, AV-over-IP displays, live production, broadcast facilities, and remote contribution workflows.
Does the 4K NDI decoder support 60 fps?
Yes. Single View supports one decoded stream at up to 4096 × 2160p60. The HDMI output also supports resolutions up to 4096 × 2160 at 60 fps.
Which NDI formats can the decoder receive?
The decoder supports NDI High Bandwidth, NDI HX2, and NDI HX3. Magewell currently lists support for NDI 6.3.
Can it decode SRT video to HDMI?
Yes. SRT is supported through MPEG-TS alongside RTP, UDP, and RIST. Additional supported protocols include RTMP, RTSP, HLS, HTTP, ZIXI, and multiple NDI formats.
Can the decoder display multiple IP sources?
Yes. Picture-in-Picture mode supports two decoded sources, while Quad View can display up to four H.264 or H.265 network streams. Single View is available when one source needs full-screen 4K60 output.
Does the HDMI output support HDR?
Yes. The HDMI 2.0 output supports PQ and HLG HDR as well as BT.601, BT.709, and BT.2020 color spaces.
Can Magewell Pro Convert IP to HDMI 4K use PoE?
Yes. The Gigabit Ethernet interface supports IEEE 802.3at PoE+. The decoder can also receive power through its USB Type-C connection.
Deploy Magewell Pro Convert IP to HDMI 4K
Coremicro is an authorized Magewell dealer for professional NDI decoders, IP video systems, live production, broadcast monitoring, and AV-over-IP workflows. Contact our team to confirm network protocol, multiview, HDR, display, and integration requirements for your installation.
