Magewell Modator 2U Chassis

Magewell Modator 2U Chassis is a rack-mountable modular platform built for professional AV and IP video systems. It holds up to 10 independent, hot-swappable Modator modules in a compact 2U frame, giving engineers one central chassis for multiple conversion or processing tasks.

Each installed module works independently, so the chassis can handle several signal paths at the same time without tying everything to one shared processing block. Dual redundant power supplies, efficient heat dissipation, a 4.8" OLED touchscreen, Gigabit Ethernet, and browser-based control make it well suited to fixed rack installations that need to stay online around the clock.

Highlights

• 10 hot-swappable module bays – supports up to 10 independent Magewell Modator modules
• 2U rack-mountable chassis – keeps multiple conversion modules together in a standard rack space
• Dual redundant power supplies – adds power redundancy for continuous operation
• 4.8" OLED touchscreen – gives engineers direct local control from the front panel
• Gigabit Ethernet – provides network access for remote management
• Web UI and API support – allows browser-based control and system integration

Quick Specs & Uses

• Product type: 2U rack-mountable modular chassis
• Module capacity: 10 x Magewell module bays
• Compatible modules: Magewell Pro Convert NDI to AIO Module, Pro Convert NDI to HDMI Module, Pro Convert HDMI Plus Module, Pro Convert HDMI 4K Plus Module
• Display: 4.8" OLED touchscreen
• USB I/O: 1 x USB-C female input
• Ethernet: 1 x RJ45 1000 Mb/s
• Power source: Built-in AC input
• AC input power: 100 to 240 VAC, 50 / 60 Hz at 3.5 to 7 A
• Maximum power consumption: 200 W
• Mounting: 10 x Magewell module bays; 4 x mounting holes; 4 x M6 screws
• Color: Black
• Operating conditions: 0 to 50°C (32 to 122°F), 5 to 90% humidity
• Storage conditions: -20 to 70°C (-4 to 158°F), 5 to 90% humidity
• Dimensions: 482 × 275 × 88 mm (19 × 10.8 × 3.5 in)
• Weight: 5.6 kg (12.3 lb)

Why It Helps

Once a system starts using several IP and baseband conversion modules, individual boxes can quickly turn into a crowded rack. The Modator 2U brings those modules into one chassis, which keeps power, cooling, control, and physical installation more organized.

The hot-swappable bays are useful when a module needs to be replaced or changed without dismantling the rest of the system. Because each module operates independently, one signal path can be serviced while the others stay in place and continue working.

Local and remote control are both covered. Engineers can use the front touchscreen when standing at the rack, or move to the browser-based Web UI and API when the chassis needs to be managed from another workstation or tied into a larger control system.

System Characteristics

• Ten-module capacity concentrates multiple conversion paths into a single 2U chassis
• Independent module operation keeps each installed signal path separate
• Hot-swappable design makes module replacement easier during continuous operation
• Dual redundant power supplies add resilience for 24/7 professional AV environments
• Touchscreen and Web UI control give engineers both local and remote management options
• API support allows the chassis to be integrated into wider control and automation systems

What's In The Box

• 1 x Magewell Modator 2U Rack-Mountable Chassis
• 1 x USB-A to USB-C Cable
• 2 x AC Power Cables
• 4 x M6 Installation Screws
