Hollyland Pyro 7 7" Wireless Transceiving Monitor

Hollyland Pyro 7 7" Wireless Transceiving Monitor is designed for production crews that need a bright field monitor with built-in wireless transmit and receive capability. Based on the source images, it features a 7" touchscreen, 1920 x 1200 resolution, 1500-nit brightness, HDMI 1.4b and 3G-SDI input/output, plus wireless operation across 5.1–5.8GHz and 2.412–2.484GHz bands.

From a broadcast engineering standpoint, the Pyro 7 is useful because it combines monitoring and wireless video workflow into one device. It can take in HDMI or SDI, loop video out, transmit wirelessly, and receive wireless video depending on the production setup. With <50ms display latency, approximately 60ms transmission latency, and a listed 1,300ft / 400m LOS range, it is built for camera teams, directors, video village, and mobile production crews that need flexible monitoring without extra boxes everywhere.

Highlights

• 7" wireless transceiving monitor for field monitoring and wireless video workflows
• 1920 x 1200 touchscreen display with 1500-nit brightness for production viewing
• HDMI 1.4b and 3G-SDI input/output for flexible camera and monitor routing
• Dual-band wireless operation across 5.1–5.8GHz and 2.412–2.484GHz
• 1,300ft / 400m LOS range, with 650ft / 200m listed in Broadcast mode

Quick Specs & Uses

• Product type: Wireless transceiving monitor
• Screen size: 7" touchscreen
• Screen resolution: 1920 x 1200 pixels
• Pixel density: 323 PPI
• Aspect ratio: 16:9
• Screen brightness: 1500 nits
• Contrast ratio: 1000:1
• Input port: HDMI 1.4b + 3G-SDI
• Output port: HDMI 1.4b + 3G-SDI
• Antenna: RP-SMA male x 2
• Power input: DC input, 2.0mm core socket
• Headphone jack: 3.5mm
• Upgrade port: USB-C USB 2.0 OTG, SD card slot
• Power input voltage: 10–18V / 2.5A DC input, nominal 12V
• Power consumption: <22W
• Operating frequency: 5.1–5.8GHz; 2.412–2.484GHz
• Transmit power: ≤23dBm
• Receiver sensitivity: -80dBm
• Display latency: <50ms
• Transmission latency: ≈60ms when 1080p60 signals are transmitted in a laboratory
• LOS range: 1,300ft / 400m; 650ft / 200m in Broadcast mode
• Bandwidth: 20MHz; 40MHz in Broadcast mode
• Audio format: HDMI 1.4b 8-channel
• Operating temperature: -10°C to 45°C
• Storage temperature: -40°C to 60°C

Why It Helps

On set, every extra box adds power, cabling, mounting, and troubleshooting. The Pyro 7 helps clean that up by combining a bright monitor with wireless video transmit and receive capability. That makes it useful on camera rigs, director stations, video village, livestream builds, and compact production carts.

The HDMI and SDI support matters in mixed production environments. A crew can work with cinema cameras, switchers, monitors, and SDI-based production paths without forcing the entire setup through one connector type. The 1500-nit display also makes the monitor more practical for bright locations where lower-brightness screens can be hard to judge.

System Characteristics

• Monitor, transmitter, and receiver workflow reduces the need for separate wireless video boxes
• Bright 7" touchscreen supports field viewing in demanding production environments
• HDMI and SDI routing fits mixed broadcast, cinema, and livestream setups
• Dual-band wireless operation gives flexibility in changing RF environments
• D-Tap power cable and accessories support field deployment out of the box

What’s In The Box

• 1 x Pyro 7 Wireless Transceiving Monitor
• 2 x Paddle Antenna (2.4 GHz & 5 GHz)
• 1 x User Manual
• 1 x Warranty Card
• 1 x D-Tap to Locking DC Power Adapter Cable
• 1 x Secure Digital Memory Card (32G)
• 1 x USB-C OTG Adapter
