Epiphan Production Essentials Bundle

Epiphan Production Essentials Bundle combines an Epiphan Pearl-2 Base Video Mixer with two EC20 4K SDI/HDMI/NDI/Dante PTZ cameras for multi-camera live production and recorded content workflows. The Pearl-2 provides the central switching, encoding, recording, and monitoring platform, while the two EC20 cameras add remote-controlled 4K-capable acquisition with 20x optical zoom.

For broadcast engineers and in-house production teams, the bundle brings the core signal chain together in one package. Pearl-2 handles 12G-SDI, HDMI/DVI, HX/NDI, professional analog audio, and 512GB of internal storage, while each EC20 supports HDMI, 3G-SDI, LAN, and USB video output along with Dante AV-H, NDI|HX2, ONVIF, RTMP/RTMPS, RTSP, and SRT IP workflows.

Highlights

• Dual-camera production package – combines a Pearl-2 Base Video Mixer with two Epiphan EC20 PTZ cameras
• 20x optical PTZ cameras – each EC20 uses a 6.25 to 125 mm lens with 20x optical and 16x digital zoom
• UHD-capable camera workflow – EC20 supports HDMI output and internal recording up to 3840 × 2160 at 60 fps
• Professional IP integration – camera streaming supports Dante AV-H, NDI|HX2, ONVIF, RTMP/RTMPS, RTSP, and SRT
• Complete camera mounting package – includes two ceiling mounts and two wall mounts for the EC20 cameras

Quick Specs & Uses

• Product type: Dual-camera live production bundle
• Production system: Epiphan Pearl-2 Base Video Mixer
• PTZ cameras: 2 x Epiphan EC20 4K SDI/HDMI/NDI/Dante PTZ Camera
• Pearl-2 processing resolution: DCI 4K
• Pearl-2 video inputs: 2 x BNC 12G-SDI; 4 x HDMI/DVI 1.4a; 1 x RJ45 HX/NDI
• Pearl-2 video outputs: 1 x HDMI 1.4a; 1 x HDMI 2.0
• Pearl-2 internal storage: 512GB
• EC20 image sensor: 1/1.8"-type CMOS, 8.42 MP effective resolution
• EC20 optical zoom: 20x
• EC20 maximum HDMI output: 3840 × 2160 at up to 60 fps
• EC20 presets: 255
• Application: Multi-camera live event production and recorded content

Why It Helps

The bundle gives an operator two remotely controlled camera positions around a dedicated production mixer, which is a practical starting point for interviews, presentations, lectures, events, and other multi-camera work. Pearl-2 keeps switching, recording, encoding, and monitoring centralized instead of spreading those functions across separate systems.

Each EC20 is built for repeatable remote operation. The cameras provide 255 presets, 325° of pan travel, 120° of tilt, a 20x optical zoom lens, tally, and PoE+ support, allowing engineers to establish useful framing positions and recall them without requiring an operator at each camera.

The signal options also support different production infrastructures. EC20 cameras can output through HDMI, 3G-SDI, LAN, or USB-C, while Pearl-2 accepts 12G-SDI, HDMI/DVI, and HX/NDI sources. A Pearl-2 4K license is listed as available separately for workflows that require expanded 4K operation.

System Characteristics

• Pearl-2 audio inputs include 4 x XLR 3-pin stereo analog female and 1 x 2RCA stereo analog female connections
• Pearl-2 audio output includes 1 x 1/8" / 3.5 mm TRS stereo analog female connection with embedded HDMI audio
• Pearl-2 IP encoding supports H.264 up to 4096 × 2160
• Pearl-2 display uses a 4.3" screen with 800 × 480 resolution
• Pearl-2 HDCP support is provided
• Pearl-2 operating conditions: 0 to 40°C (32 to 104°F)
• Pearl-2 dimensions: 300 × 240 × 89.9 mm (11.81 × 9.45 × 3.54 in)
• Pearl-2 weight: 3.8 kg (8.4 lb)
• EC20 shutter speed ranges from 1/10,000 to 1/30 second
• EC20 signal-to-noise ratio: 55 dB
• EC20 minimum illumination: 0.5 lux
• EC20 lens uses a 6.25 to 125 mm focal range with f/1.58 to 3.95 maximum aperture
• EC20 video outputs include 1 x HDMI, 1 x BNC 3G-SDI, 1 x RJ45 LAN, and 1 x USB-C
• EC20 embedded audio is supported over HDMI, IP/LAN, SDI, and USB
• EC20 built-in microphone is stereo
• EC20 internal recording supports 3840 × 2160, 1920 × 1080, and 1280 × 720 at up to 60 fps
• EC20 audio recording supports AAC audio
• EC20 IP streaming supports H.264, H.265, and MJPEG via Dante AV-H, HTTP, NDI|HX2, ONVIF, RTMP/RTMPS, RTSP, and SRT
• EC20 control provides 255 presets with pan from -162.5° to 162.5° and tilt from -30° to 90°
• EC20 serial control includes RS-232 and RS-485 connectivity
• EC20 tally light is included
• EC20 PoE support: PoE+ 802.3at
• EC20 power: 12 VDC, 2 A (18 W)
• EC20 operating conditions: 0 to 40°C (32 to 104°F)
• EC20 storage conditions: -40 to 60°C (-40 to 140°F)
• EC20 dimensions: 223 × 165 × 154.8 mm (8.8 × 6.5 × 6.09 in)
• EC20 weight: 1.8 kg (4 lb), body only

What's In The Box

• 1 x Epiphan Pearl-2 Base Video Mixer
• 1 x Ethernet Cable
• 1 x Power Cable (6')
• 1 x SDI Cable (3')
• 1 x HDMI Cable (3')
• 1 x DVI (F) to HDMI (M) Adapter
• 1 x Hard-Shell Carrying Case
• 2 x Epiphan EC20 4K SDI/HDMI/NDI/Dante PTZ Camera with 20x Optical Zoom
• 2 x Remote Controller
• 2 x 12 VDC Power Adapter
• 2 x Ceiling Mount
• 2 x Wall Mount
