DZOFilm PAVO 40mm T2.1 2x Anamorphic Prime Lens Neutral PL/EF

A Balanced Perspective for Narrative and Environmental Coverage

The 40mm focal length sits between the wider PAVO options and longer normal-to-telephoto focal lengths, providing enough field of view to retain environmental context while placing greater visual emphasis on the subject.

Its 2X anamorphic optical design adds horizontal compression, oval bokeh, and characteristic flare behavior while maintaining a versatile perspective for medium-wide narrative compositions.

Fast Operation for Available-Light and Controlled Sets

The PAVO 40mm opens to T2.1, supporting lower-light production environments and selective depth-of-field control while retaining its medium-wide Super35 perspective.

The aperture range extends to T22, giving cinematographers additional exposure flexibility across interior, exterior, and controlled studio-lighting conditions.

Neutral Flare Rendering for Flexible Lighting Design

This exact DZO-PA4021PLIN model is the Neutral-coated version of the PAVO 40mm. It produces horizontal anamorphic flare behavior without the dedicated blue flare treatment used by the separate Blue configuration.

The Neutral version allows practical sources and production lighting to play a larger role in determining flare color while retaining the characteristic streak structure of anamorphic optics.

Compact Anamorphic Design for Professional Camera Builds

The PAVO 40mm measures approximately 107.6mm from the front of the lens to the flange plane and weighs about 1300g, providing a relatively compact 2X anamorphic option for professional Super35 production.

Its 95mm front diameter and standardized cine-style mechanical layout help simplify matte-box, follow-focus, and lens-change workflows when the 40mm is used alongside other PAVO focal lengths.

Interchangeable Mounting for Professional Cinema Cameras

The PAVO 40mm supports interchangeable PL and EF mounting, allowing camera departments to configure the lens for compatible professional cinema-camera systems.

The PAVO platform also incorporates back-focus adjustment, supporting precise setup when changing mounts or integrating the lens into different camera packages.

Manual Focus and Iris Control for Camera Crews

Standard 0.8 MOD gearing supports compatible follow-focus systems and lens-control motors used in professional cinema workflows.

This DZO-PA4021PLIN configuration uses Imperial focus markings in feet, while the 0.45m minimum focus distance supports closer subject placement and foreground interaction within medium-wide compositions.

What is the DZOFilm PAVO 40mm T2.1 used for?

The DZOFilm PAVO 40mm T2.1 is a Super35 2X anamorphic prime designed for professional cinema production. Its medium-wide perspective works well for narrative coverage, interiors, environmental portraits, commercial work, and compositions that balance subject presence with surrounding context.

What anamorphic squeeze does the PAVO 40mm use?

The PAVO 40mm uses a true 2X anamorphic squeeze. Footage should be appropriately de-squeezed during monitoring or post-production to display the intended widescreen image.

What does the Neutral version of the PAVO 40mm produce?

DZO-PA4021PLIN is the Neutral-coated version of the PAVO 40mm. It produces neutral horizontal anamorphic flares and characteristic oval or waterfall-style bokeh without the dedicated blue flare treatment of the separate Blue version.

Is the DZOFilm PAVO 40mm a full-frame lens?

No. The PAVO 40mm is designed for Super35 / APS-C coverage with a 31.5mm image circle rather than native full-frame coverage.

How close can the PAVO 40mm focus?

The PAVO 40mm focuses down to 0.45m, or approximately 1 ft 6 in, measured from the sensor plane. This allows closer subject placement while retaining the lens's medium-wide perspective.

Does the PAVO 40mm support PL and EF mounts?

Yes. The lens uses an interchangeable mount system for compatible ARRI PL and Canon EF camera configurations. An EF bayonet is included with the lens.

What front diameter and cine gearing does the PAVO 40mm use?

The PAVO 40mm uses a 95mm front diameter, M86 filter thread, and standard 0.8 MOD cine gearing for compatible matte boxes, follow-focus units, and motorized lens-control systems.
