DZOFilm PAVO 28mm T2.1 2x Anamorphic Prime Lens Neutral PL/EF

Wide Environmental Framing with Anamorphic Depth

The 28mm focal length gives cinematographers a broad Super35 field of view for establishing shots, interiors, environmental coverage, and compositions that place a subject within a larger visual space.

The 2X anamorphic optical design adds horizontal compression, oval bokeh, and anamorphic flare behavior while retaining the wider perspective needed for immersive compositions and foreground-to-background layering.

Fast Wide-Angle Operation for Controlled Depth of Field

The PAVO 28mm opens to T2.1, providing the widest maximum aperture used by this focal length in the PAVO series. The aperture range extends to T22 for additional exposure control when working under brighter production lighting.

At wider settings, cinematographers can combine the 28mm field of view with selective focus and foreground separation while preserving the lens's 2X anamorphic rendering.

Neutral Flare Rendering for Flexible Lighting Design

This exact DZO-PA2821PLIN model is the Neutral configuration of the PAVO 28mm. It produces horizontal anamorphic flare behavior without the dedicated blue flare treatment used by the separate Blue version.

The Neutral option is suited to productions that want classic anamorphic flare structure while retaining more flexibility over the color introduced by practical sources and production lighting.

Production-Ready 28mm Design for Flexible Camera Builds

The PAVO 28mm measures approximately 106.3mm from the front of the lens to the flange plane and weighs about 1203g, giving camera crews a comparatively compact wide-angle anamorphic option for professional production.

Its 95mm front diameter and unified cine-style mechanical layout help simplify matte-box, follow-focus, and lens-change workflows when the 28mm is used as part of a larger PAVO lens package.

Interchangeable Mounting for Professional Cinema Cameras

The PAVO 28mm supports interchangeable PL and EF mounting, allowing camera departments to configure the lens for compatible professional cinema-camera systems.

The PAVO platform also incorporates back-focus adjustment, supporting precise setup when changing mounts or integrating the lens into different camera packages.

Manual Focus and Iris Control for Camera Crews

Standard 0.8 MOD gearing supports compatible follow-focus systems and lens-control motors used in professional cinema workflows.

This DZO-PA2821PLIN configuration uses Imperial focus markings in feet, while its 0.4m minimum focus distance gives focus pullers additional flexibility for close foreground work with the wide 28mm field of view.

What is the DZOFilm PAVO 28mm T2.1 used for?

The DZOFilm PAVO 28mm T2.1 is a wide-angle Super35 2X anamorphic prime designed for professional cinema production. Its wide field of view is useful for establishing shots, interiors, environmental compositions, and close wide-angle coverage.

What anamorphic squeeze does the PAVO 28mm use?

The PAVO 28mm uses a true 2X anamorphic squeeze. Footage should be appropriately de-squeezed during monitoring or post-production to display the intended widescreen image.

What does the Neutral version of the PAVO 28mm produce?

DZO-PA2821PLIN is the Neutral-coated version of the PAVO 28mm. It produces elegant horizontal anamorphic flare behavior without the dedicated blue treatment used by the separate Blue-coated configuration.

Is the DZOFilm PAVO 28mm a full-frame lens?

No. The PAVO 28mm is designed for Super35 / APS-C coverage with a 31.5mm image circle rather than full-frame coverage.

How close can the PAVO 28mm focus?

The PAVO 28mm focuses down to approximately 0.4m, or 1 ft 4 in, measured from the sensor plane. This allows foreground elements to be positioned relatively close to the camera while retaining the wide 28mm perspective.

Does the PAVO 28mm support PL and EF mounts?

Yes. The lens uses an interchangeable mount system for compatible ARRI PL and Canon EF camera configurations. An EF bayonet is included with the lens.

What front diameter and cine gearing does the PAVO 28mm use?

The PAVO 28mm uses a 95mm front diameter, M86 filter size, and standard 0.8 MOD gearing for integration with compatible matte boxes, follow-focus units, and motorized lens-control systems.
