DZOFilm PAVO 180mm T2.8 2x Anamorphic Prime Lens Neutral PL/EF

Maximum PAVO Compression for Strong Subject Isolation

The 180mm focal length provides the longest telephoto perspective in the PAVO series. Its compressed field of view reduces the apparent distance between foreground and background while supporting shallow depth of field for isolated subjects and tighter compositions.

DZOFilm specifically positions the 135mm and 180mm focal lengths as telephoto additions for stronger environmental compression and character isolation while maintaining the unified 2X anamorphic rendering of the PAVO family.

Evenly Layered Neutral Flares for Flexible Cinema Lighting

This exact DZO-PA18028PLIN model is the Neutral flare version of the PAVO 180mm. Its anamorphic optical design produces evenly layered horizontal streak flares without the dedicated blue treatment used by the alternate Blue version.

DZOFilm offers separate Neutral and Blue versions across the PAVO line, allowing cinematographers to match flare character to the intended visual style of a production.

Extend the PAVO System to 180mm Telephoto Coverage

The PAVO 180mm extends the series to its longest focal length, giving cinematographers pronounced spatial compression and shallow depth of field while maintaining the 2X anamorphic character of the PAVO family.

The lens uses a 95mm front diameter, measures approximately 160mm from the front of the lens to the flange plane, and weighs about 1950g.

Interchangeable Mounting for Professional Cinema Cameras

The PAVO 180mm supports interchangeable PL and EF mounting, allowing camera departments to configure the lens for compatible professional cinema-camera systems.

DZOFilm also incorporates built-in back-focus adjustment into the PAVO platform, allowing crews to make precise corrections while the lens remains mounted to the camera.

Manual Focus and Iris Control for Cinema Crews

Standard 0.8 MOD gearing supports compatible follow-focus systems and lens-control motors for professional camera operation.

This DZO-PA18028PLIN configuration uses Imperial focus markings in feet, supporting camera departments and focus pullers working with feet-based distance measurements.

What is the DZOFilm PAVO 180mm T2.8 used for?

The DZOFilm PAVO 180mm T2.8 is a Super35 2X anamorphic telephoto prime designed for professional cinema production. Its long focal length supports tight compositions, compressed perspective, shallow depth of field, and strong subject isolation.

What anamorphic squeeze does the PAVO 180mm use?

The PAVO 180mm uses a true 2X anamorphic squeeze. Recorded footage must be appropriately de-squeezed during monitoring or post-production to display the intended widescreen image.

What does the Neutral flare version look like?

DZO-PA18028PLIN is the Neutral flare version of the PAVO 180mm. It produces evenly layered horizontal anamorphic streaks without the dedicated blue treatment used by the separate Blue version.

Is the DZOFilm PAVO 180mm a full-frame lens?

No. The PAVO 180mm is designed around a 31.5mm Super35 image circle. Its native optical coverage is Super35 rather than full frame.

Does the PAVO 180mm support PL and EF mounts?

Yes. The lens uses an interchangeable mounting system for compatible ARRI PL and Canon EF cinema-camera configurations. An EF bayonet is included with the lens.

How close can the PAVO 180mm focus?

The PAVO 180mm has a minimum focus distance of 1.04m, or approximately 3 ft 5 in, measured from the camera sensor plane.

What front diameter and filter size does the PAVO 180mm use?

The PAVO 180mm uses a 95mm front diameter and an M86 filter thread. Standard 0.8 MOD gearing supports compatible follow-focus and cinema lens-control systems.
