DZOFilm PAVO 100mm T2.4 2x Anamorphic Prime Lens Neutral PL/EF

Classic Anamorphic Character with Controlled Optical Performance

The PAVO optical design combines a true 2X squeeze with the visual characteristics associated with anamorphic filmmaking. Horizontal flare behavior, elliptical bokeh, and smooth focus transitions give cinematographers a distinctive widescreen image for narrative and commercial production.

DZOFilm designs the PAVO series to balance this anamorphic character with controlled chromatic aberration, distortion, image detail, and natural color rendition.

Neutral Horizontal Flares for Flexible Cinema Lighting

This exact DZO-PA10021PLIN lens uses DZOFilm's Neutral coating configuration. It retains the horizontal flare behavior of the PAVO anamorphic design while avoiding the dedicated blue flare treatment used on the separate Blue version.

The Neutral and Blue models are separate product configurations, so coating type should be matched carefully when adding the 100mm lens to an existing PAVO set.

Compact 2X Anamorphic Optics for Modern Camera Rigs

The PAVO 100mm weighs approximately 1654g and uses a 95mm front diameter, keeping the lens compact relative to many traditional anamorphic systems while maintaining professional cine-lens mechanics.

DZOFilm designs the PAVO series for a range of production configurations including handheld, gimbal, Steadicam, and supported aerial camera systems.

Interchangeable Mounting for Professional Cinema Cameras

PAVO lenses support interchangeable PL and EF mounts, allowing crews to adapt the same optical platform to compatible cinema camera systems without moving to a different lens series.

A built-in back-focus adjustment provides a direct way to make precise corrections while adapting the lens to different camera bodies or changing mount configurations.

Built for Follow-Focus and Cinema Lens-Control Workflows

Standard 0.8 MOD gearing allows compatible follow-focus units and lens-control motors to interface with the PAVO 100mm during professional production.

This Imperial version uses focus markings in feet, making it suitable for camera departments and focus pullers working with feet-based distance measurements.

What is the DZOFilm PAVO 100mm T2.4 used for?

The DZOFilm PAVO 100mm T2.4 is a Super35 2X anamorphic prime designed for professional cinema production. The longer focal length is suited to tighter compositions, compressed perspective, subject isolation, and character-focused shots.

What anamorphic squeeze does the PAVO 100mm use?

The PAVO 100mm uses a true 2X anamorphic squeeze. Recorded footage must be appropriately de-squeezed during monitoring or post-production to display the intended widescreen image.

Is the DZOFilm PAVO 100mm a full-frame lens?

No. The PAVO 100mm is designed around a 31.5mm Super35 image circle. Its native optical coverage is Super35 rather than full frame.

What does Neutral coating mean on the PAVO 100mm?

DZO-PA10021PLIN is the Neutral coating version of the PAVO 100mm. DZOFilm also produces a separate Blue version, so the two flare treatments are separate product configurations.

Does the PAVO 100mm support PL and EF mounts?

Yes. The PAVO system uses interchangeable PL and EF mounts, allowing the lens to be configured for compatible professional cinema cameras using either mount.

How close can the PAVO 100mm focus?

The PAVO 100mm has a minimum focus distance of 0.95m, or approximately 3 ft 1 in, measured from the sensor plane.

What front diameter and filter size does the PAVO 100mm use?

The lens uses a 95mm front diameter and an M86 filter thread. It also uses standard 0.8 MOD cine gearing for compatible follow-focus and lens-control systems.
