DATAVIDEO 4K Multi-Camera Processing Switcher with Built-In PTZ Camera Control

DATAVIDEO 4K Multi-Camera Processing Switcher with Built-In PTZ Camera Control is built for productions that need switching, streaming, recording, and camera control to happen in one place instead of across multiple separate boxes. Based on the source details, this is the KMU-300, a portable multi-camera touchscreen switcher designed around a 14 inch capacitive touch display, UHD 4K input support, built-in H.264 streaming, SD card recording, and integrated PTZ camera control.

Highlights

• Touchscreen multi-camera switcher built for integrated live production workflows
• UHD 4K input support with HD output for processed live production delivery
• Built-in streaming and recording system for simultaneous live and local workflow handling
• 14 inch capacitive touch display provides a centralized operating surface
• Built-in PTZ camera control and 4-channel audio mixer reduce the need for separate control devices

Quick Specs & Uses

• Product name: DATAVIDEO 4K Multi-Camera Processing Switcher with Built-In PTZ Camera Control
• Model number: KMU-300
• Video standard: UHD and HD
• Video input formats: 3840 x 2160p 23.98/24/25/29.97/30/50/59.94/60, 1080p 50/59.94/60
• Video output formats: 1080p 50/59.94/60, 720p 50/59.94/60
• Video processing: 4:4:4 / 4:2:2 / 4:2:0
• Video inputs: 1 x HDMI 2.0, 1 x HDMI 1.4 with loop through
• Video outputs: 3 x HDMI 1.4 program, 1 x HDMI 1.4 aux
• Preview display: 14 inch capacitive touch LCD
• Streaming encode: H.264/AVC Main and High Profile
• Streaming protocols: TS over TCP/UDP, RTSP over HTTP/TCP/UDP, RTMP/RTMPS, HLS, SRT
• Network interface: 1 x RJ45 10/100 Mbps Ethernet
• Recording medium: SD card Class 10 and above
• Recording file system: NTFS, FAT, exFAT
• Recorded file format: MP4
• Audio inputs: 2 x XLR mic, 2 x RCA
• Audio outputs: 2 x unbalanced RCA
• Built-in audio mixer: yes, 4 channels
• Power supply: DC 12V, 52W
• Dimensions: 438 x 331 x 114 mm
• Weight: 4.3 kg
• Operating temperature: 0 to 40°C

Why It Helps

In a real live production workflow, the challenge is rarely just switching sources. It is also handling stream delivery, local recording, audio, and camera control without spreading the job across too many devices. This switcher makes sense because it pulls those functions into one operating surface, which can simplify both setup and show operation.

System Characteristics

• 4K-capable input processing gives the switcher room for higher-resolution source handling before HD output
• Touchscreen-based control surface keeps live operation centered in one compact unit
• Built-in streaming and recording support both live delivery and local backup at the same time
• PTZ control integration helps reduce the need for separate camera-control hardware
• Mixed audio I/O and internal mixing make the unit more self-contained for smaller productions

What’s In The Box

Please refer to the Specifications tab for the exact included items.
