DATAVIDEO 4-Channel Long-Range HDBaseT Receiver with HDMI, 3G-SDI Outputs

DATAVIDEO 4-Channel Long-Range HDBaseT Receiver with HDMI, 3G-SDI Outputs is built for systems that need to bring multiple remote camera feeds back to the rack without turning the signal path into a converter project. Based on the source details, this is a 4-channel HDBaseT receiver with 4 RJ45 HDBaseT inputs, 4 HDMI 2.0 outputs, and 4 BNC 3G-SDI outputs. It supports 1080p transmission up to 328.1 feet or 100 meters over Cat 6a, while also carrying camera-related control functions for more complete infrastructure workflows.

Highlights

• 4-channel long-range HDBaseT receiver for multi-camera transport systems
• 4 RJ45 HDBaseT inputs with output conversion to HDMI and 3G-SDI
• Supports 1080p transmission up to 328.1 feet or 100 meters over Cat 6a cabling
• Simultaneous HDMI, 3G-SDI, RS-422, and IR signal support for integrated camera workflows
• Rack-style chassis with IEC C14 power input for installed production environments

Quick Specs & Uses

• Product name: DATAVIDEO 4-Channel Long-Range HDBaseT Receiver with HDMI, 3G-SDI Outputs
• Transmission I/O: 4 x RJ45 HDBaseT input
• HDMI output: 4 x HDMI 2.0 output
• 3G-SDI output: 4 x BNC 3G-SDI output
• Embedded audio: RJ45, HDMI
• Power input: 1 x IEC C14
• HDCP support: no
• EDID support: no
• Maximum transmission distance: 1080p at 60 Hz, 328.1 feet / 100 m
• Supported video format: 1920 x 1080p at 25, 29.97, 30, 50, 59.94, 60, 23.98, and 24 fps
• Supported interlace format: 1920 x 1080i at 50, 59.94, and 60 fps
• Supported cable type: Cat 6a
• Operating conditions: 32 to 104°F / 0 to 40°C
• Dimensions: 17.3 x 11.3 x 1.9 in / 440 x 286 x 49 mm
• Weight: 9.3 lb / 4.2 kg
• Included items: receiver, AC cord
• Not included: transmitters

Why It Helps

Long cable runs are easy to justify on paper and harder to keep clean in the field. That is where a receiver like this earns its place. Instead of treating each remote camera as a separate conversion problem, this unit gives the system a centralized way to bring back multiple 1080p HDBaseT feeds and hand them off as HDMI and 3G-SDI. For integrators and production teams, that usually means a tidier rack, fewer boxes at the camera end, and a more controlled path back into the switcher or router.

System Characteristics

• 4-channel architecture makes the unit better suited to multi-camera systems than single-link extension hardware
• HDMI and 3G-SDI outputs on every channel give the receiver more flexibility inside mixed signal environments
• Support for RS-422 and IR control signals adds value beyond basic video transport
• 100 meter Cat 6a transmission distance fits longer camera runs in installed and event workflows
• Rack-oriented chassis design makes deployment cleaner in production and AV infrastructure builds

What’s In The Box

DATAVIDEO 4-Channel Long-Range HDBaseT Receiver with HDMI, 3G-SDI Outputs and AC cord. Please refer to the Specifications tab for the exact included items.
