DATAVIDEO 3-Channel Long-Range HDBaseT Receiver with HDMI Outputs

DATAVIDEO 3-Channel Long-Range HDBaseT Receiver with HDMI Outputs is designed for setups where multiple remote camera feeds need to come back to a central system without adding extra hardware at every endpoint. Based on the source details, this is a 3-channel HDBaseT receiver with 3 RJ45 inputs and 3 HDMI 2.0 outputs, supporting both UHD 4K and HD signals over distance. It also carries RS-422 and IR control, which helps keep camera control integrated with the video path.

In real-world use, this kind of unit helps simplify the signal chain. Cameras stay where they need to be, while everything returns cleanly to the rack. With support for runs up to 328.1 feet or 100 meters over Cat 6a, it fits well into installed systems, live production setups, and multi-camera workflows that need reliable long-distance transport.

Highlights

• 3-channel HDBaseT receiver for multi-camera transport
• 3 RJ45 inputs with HDMI 2.0 output conversion
• Supports 4K and HD transmission up to 100 meters over Cat 6a
• RS-422 and IR control support for integrated workflows
• Rack-ready design for installed production environments

Quick Specs & Uses

• Product name: DATAVIDEO 3-Channel Long-Range HDBaseT Receiver with HDMI Outputs
• Transmission I/O: 3 x RJ45 HDBaseT input
• HDMI output: 3 x HDMI 2.0 output
• Embedded audio: RJ45, HDMI
• Power input: 1 x XLR 4-pin, 56 VDC
• HDCP support: no
• EDID support: no
• Maximum transmission distance: 328.1 feet / 100 m
• Supported formats: 4K, 1080p, 1080i, 720p
• Supported cable type: Cat 6a
• Video bandwidth: 18 Gb/s
• Operating conditions: 32 to 104°F / 0 to 40°C
• Dimensions: 17.3 x 4.9 x 1.8 in / 440 x 125 x 44.5 mm
• Weight: 4 lb / 1.8 kg

Why It Helps

Running long cable distances is rarely the problem. Keeping the signal path clean is. A receiver like this keeps things centralized so you are not stacking converters at every camera position. Everything comes back through one unit, ready for switching or monitoring. That usually means fewer points of failure and a setup that is easier to manage over time.

System Characteristics

• 3-channel architecture supports multi-camera setups without separate receivers
• HDMI output per channel fits standard switching and monitoring workflows
• 4K and HD support works with both modern and legacy camera systems
• Integrated control transport carries RS-422 and IR signals alongside video
• Long-distance transmission supports up to 100 meter runs over Cat 6a

What’s In The Box

Please refer to the Specifications tab for the exact included items.
