Atomos Ninja TX GO Monitor-Recorder for HDMI Cameras

Atomos Ninja TX GO Monitor-Recorder for HDMI Cameras is designed as the HDMI-only companion to the Ninja TX. It gives compact camera setups a 5.2" 1920 x 1080 IPS touchscreen, 1500 cd/m² brightness, HDMI 2.0 input/output, and recording support to CFexpress Type B or USB-C.

For camera operators, this unit brings monitoring, recording, camera control, touch-to-focus, Wi-Fi connectivity, and TX/RX streaming support into one compact monitor-recorder. It is especially useful when the camera needs a brighter screen, better monitoring tools, and a more production-ready recording path.

Highlights

• 5.2" 1920 x 1080 IPS touchscreen
• 1500 cd/m² brightness
• HDMI 2.0 input and output
• Records to CFexpress Type B slot and USB-C
• Supports up to 6K30 ProRes RAW video

Quick Specs & Uses

• Panel type: IPS-Type LCD
• Display size: 5.2" / 13.2 cm
• Native resolution: 1920 x 1080
• Touchscreen: Yes
• Brightness: 1500 nits / cd/m²
• Video I/O: 1 x HDMI 2.0 input, 1 x HDMI 2.0 output
• Media slot: CFexpress Type B for record, LUT, and firmware
• Wireless: Wi-Fi 6E dual-band 2.4 & 5 GHz
• Power: 6.2 to 16.8 VDC, 30W
• Weight: 14.1 oz / 400 g

Why It Helps

On small HDMI camera builds, a brighter monitor-recorder can make the rig much easier to operate. The Ninja TX GO gives the operator a clearer display, recording options, and built-in monitoring tools without moving into a larger production monitor.

The locking cable adapters and Wi-Fi antenna kit also help keep the setup more stable when the monitor is being used on a camera rig, gimbal, cart, or handheld build.

System Characteristics

• Image controls: anamorphic de-squeeze, blue only, false color, focus peaking, image flip, OSD flip, RGB parade, screen markers, vectorscope, waveform, zebra
• Video formats: 6K RAW 60/30, 3.5K RAW 60, DCI 4K, UHD 4K, 1080p, 1080PsF, 1080i, and 720p
• Encoding formats: DNxHD, DNxHR, ProRes 422, ProRes RAW, and H.265 options
• Audio: HDMI/IP/NDI/USB embedded audio, 3.5mm input, and 3.5mm headphone output
• Mounting: ARRI anti-twist 1/4"-20 and 2 x 3/8"-16 female mounting points

What’s In The Box

• 1 x Ninja TX GO monitor-recorder
• 1 x USB-C locking cable adapter
• 1 x HDMI locking cable adapter
• 1 x USB-C locking cable (45cm)
• 2 x Wi-Fi antennas
• 5 x antenna tip sets: black, white, yellow, green, red
• 1 x Quick Start Guide
