AJA openGear 1-Channel 12G-SDI to Single Mode ST Fiber Transmitter

AJA openGear 1-Channel 12G-SDI to Single Mode ST Fiber Transmitter is the kind of unit that makes sense when you need to move an SDI signal onto fiber cleanly while still keeping a local SDI handoff available. Based on the image source, it accepts 1-channel 12G-SDI over BNC, supports 270 Mbps to 12 Gbps in a format-agnostic design, and provides both a reclocked 12G-SDI loop output and a single-mode fiber output.

Highlights

• Format support from 270 Mbps to 12 Gbps across mixed SDI workflows
• 12G-SDI BNC input for direct coax handoff into fiber transport
• Reclocked 12G-SDI loop output for local monitoring or routing
• Single-mode fiber output for longer-distance signal extension
• Compact low-power design with an included universal power supply

Quick Specs & Uses

• Video formats: 270 Mbps to 12 Gbps, format agnostic
• Video input: 1-channel 12G-SDI BNC connector
• Supported input standards: SMPTE 259, 292, 424, 2081, 2082
• Loop output: 1-channel reclocked 12G-SDI BNC
• Fiber output: 1-channel single-mode LC fiber
• Supported fiber standards: SMPTE 297, 259, 292, 424, 2081, 2082
• Nominal wavelength: Tx 1260 nm minimum, 1310 nm typical, 1360 nm maximum
• Optical power: -5 dBm minimum, 0.5 dBm maximum
• Extinction ratio: 3.5 minimum
• Reclocking: automatic on listed standard rates, other rates passed through
• Size: 4.6 x 1.71 x 0.85 in / 117.0 x 43.5 x 21.6 mm
• Weight: 0.4 lb / 0.2 kg
• Power: 2 watts max, 5-20VDC, universal power supply included
• Operating temperature: 0 to 40°C
• Storage temperature: -40 to 60°C
• Operating humidity: 10 to 90% noncondensing
• Operating altitude: below 3,000 meters / 10,000 feet

Why It Helps

This unit helps when a single SDI path needs to move onto fiber without giving up a local coax output in the rack. It gives you a cleaner transport path, reclocks the most common SDI rates, and keeps the signal chain simple for routing, monitoring, or longer-distance infrastructure runs.

System Characteristics

• Format-agnostic operation makes the unit more flexible across mixed-format facilities.
• Reclocked loop out is useful for local distribution and confidence monitoring
• Single-mode fiber transmission supports cleaner long-distance signal extension.
• Compact physical design keeps the install simple on benches, in flypacks, or in permanent racks.
• Low power draw makes it easier to integrate into existing infrastructure

What’s In The Box

1 x AJA openGear 1-Channel 12G-SDI to Single-Mode ST Fiber Transmitter
1 x SFP Connector
1 x Rear I/O Card
