AJA KONA IP25

The AJA KONA IP25 is a powerful AJA IP capture card made for live video over IP networks. This PCIe 4.0 card supports uncompressed video, audio, and data over SMPTE ST 2110. It features two SFP cages for 10 or 25 GigE and one RJ-45 for 1 GigE. With built-in PTPv2 and NMOS, the KONA IP25 handles all IP timing and control onboard—so your computer doesn’t have to.

Built for performance, the AJA KONA IP25 supports up to 4 channels of 10-bit 4:2:2 video at 4K60. Future updates will add support for 12-bit 4:4:4. The card also handles up to 16 audio channels per stream and supports full HDR workflows. It’s a complete solution for broadcast and post-production teams moving from SDI to IP.

This AJA IP capture card works with leading software like Adobe Premiere Pro, Final Cut Pro, Avid Media Composer, and more. AJA’s own Control Room and Control Panel apps give you capture, playout, and full configuration tools. Whether you're editing, streaming, or doing visual effects, the KONA IP25 fits right in.

For developers, the KONA IP25 uses AJA’s proven SDK. It’s easy to build apps for video, audio, or graphics using SMPTE ST 2110. You can start with AJA’s open-source developer tools or join the AJA Developer Program for advanced features and support. This card supports macOS, Windows, and Linux, including the latest Apple silicon.

The KONA IP25 meets all major SMPTE IP video standards:

• ST 2110-10 (timing)

• ST 2110-20 (video)

• ST 2110-30 (audio)

• ST 2110-40 (ancillary data)

• ST 2022-7 (redundant streaming)

Use it for playback, capture, or live graphics overlays in ST 2110 networks. Redundant streaming protects your workflow from signal loss. The card uses In-Band control via SFPs or Out-of-Band via the RJ-45 port.

The KONA IP25 is built for high-end IP video workflows, from 4K live production to post. It delivers low-latency performance, smooth playback, and easy setup. You’ll get the full KONA experience—now in a powerful 25G AJA IP capture card.

With AJA’s world-class support and a 3-year warranty, the KONA IP25 is the smart choice for professional video over IP.
