AIDA Imaging HD3G-IPC-100A Full HD 3G-SDI POV Camera with IP Control

AIDA Imaging HD3G-IPC-100A is built for installations where the camera needs to stay compact, output over a broadcast-friendly format, and still be manageable once it is mounted. With a 4mm CS-mount lens, 80° field of view, 3G-SDI output, VISCA over IP control, and PoE support, it gives you a practical way to add fixed-position coverage in compact AV and broadcast environments.

Highlights

• 1/2.8" Sony progressive CMOS sensor with support up to 1080p60
• 4mm CS-mount lens for wide-angle fixed-position coverage
• 80° field of view for broader scene capture
• 3G-SDI output for cleaner integration into professional systems
• VISCA over IP control with PoE and 12 VDC power support

Quick Specs & Uses

• Sensor: 1/2.8" Sony progressive CMOS
• Effective pixels: 1920 x 1080
• Resolution support: 1080p, 1080i, 720p
• Frame rates: up to 1080p60
• Color space: 4:2:2 (YCbCr) 10-bit
• Minimum illumination: 0.2 lux day / 0.1 lux night
• Lens: 4mm CS mount
• Field of view: 80°
• Video output: 1 x BNC (3G-SDI)
• Audio input: 1 x 3.5 mm TRS line input

Why It Helps

Many compact cameras are easy to place, but harder to manage once they are installed. This model helps by combining wide-angle coverage, SDI output, remote IP control, and flexible power options in one small body. That makes it easier to deploy in tight or hard-to-reach positions while still keeping the camera aligned with a professional signal and control workflow.

System Characteristics

• Wide 80° field of view helps capture more of the scene from close mounting positions
• 3G-SDI output keeps the signal path aligned with professional video infrastructure
• VISCA over IP control makes remote management more practical in fixed installs
• PoE and 12 VDC support simplify installation planning
• Top and bottom 1/4"-20 mounting points improve rigging flexibility

What’s In The Box

Please refer to the Specifications tab for the exact included items.
